A - Canopy Dimensions 10"L x 2"W x 1.5"H
E - Bar Dimensions 0.5"D x 20"L
F - Shade Dimensions F1: 2"D x 3"H (Shade) F2: 1.5"D x 1.8"-2.2"H
(Top Shade)
F3: 0.5"D x 1.5"H (Connector)
F - Adjustor 3"L
B - Canopy Plate Dimensions 11"L x 3"W
C - Overall Height 9"H
D - Max Width 59"H
TriOS LED 6 x 4.5 W 2400 Lumens
Quattro Dimmable Material: Metal/Glass
