Page 104 - Handout Digital Electronics

Self-assessment exercise

1 Why is it that the asynchronous SR flip flop is not commercially available?

2 Consider the clocked SR flip flop below:

Produce its truth table starting from the R input. Compare the truth table you produced from the previous
produced by starting tracing the signal from the SR input. What does this tell you?

3 Control signals Pr eset and Clear are important when dealing with the SR flip flop, why?

Lecture 12 Video Lecture

Watch the complete explanation of this chapter here:
https://www.youtube.com/watch?v=MC8xK7c7yAo

Lecture 12 Online Quiz

Test your understanding by completing the quiz:
