Page 163 - 2022-23 Auto Performance Open Wheel Catalog

3-D H-Beam Connecting Rods
Durable and affordable 3-D forged rods are sized and finished in the U.S.A., and fitted with ARP 7/16", 190,000 PSI cap screw bolts. Many are available with premium ARP L-19, 265,000 PSI fasteners (add the suffix “L19” to the part number). All rods have alignment sleeves to positively lo- cate the rod cap, assuring big end bore size and eliminating cap walk. Rods are bushed for use with full-floating pins. Sold in weight-matched sets.
Center-to-Center Gram Crank Big Part No. Description Length Weight Pin Dia. End Width
Pin End Bore
SB Chevy
EAGCRS5700B3D *
Large Journal, 327, 350
5.700"
630
2.100"
.940"
.927"
EAGCRS5700S3D
Small Journal, 283, 327
5.700"
670
2.000"
.940"
.927"
EAGCRS5850B3D
Large Journal, +.150"
5.850"
650
2.100"
.940"
.927"
EAGCRS6000B3D *
Large Journal, +.300"
6.000"
640
2.100"
.940"
.927"
EAGCRS6000BLW †
Large Journal, +.300", Lightweight
6.000"
545
2.100"
.940"
.927"
EAGCRS6000B3D2000
Large Journal, +.300", Extreme Duty
6.000"
645
2.100"
.940"
.927"
EAGCRS6000B3DL19
Large Journal, +.300", L19
6.000"
645
2.100"
.940"
.927"
EAGCRS6000S3D
Small Journal, +.300"
6.000"
680
2.000"
.940"
.927"
EAGCRS6000S3D2000
Small Journal, +.300", Extreme Duty
6.000"
660
2.000"
.940"
.927"
EAGCRS6000BST
Large Journal, Max Stroke
6.000"
645
2.100"
.940"
.927"
EAGCRS6125B3D
Large Journal, +.425"
6.125"
660
2.100"
.940"
.927"
EAGCRS6125B3DL19
Large Journal, +.425", L19
6.125"
660
2.100"
.940"
.927"
* Also stocked in ESP armor finish, simply add “9” prior to rod length.
† Featherweight rods are for applications with UNDER 500 horsepower only.
Perform-O-Flex Hose
Earl’s Perform-O-Flex stainless steel braided hose has been the choice of top racing teams since 1972. Perform-O-Flex can be used with Swivel Seal, Auto-Fit, or Auto-Mate hose ends and consists of an inner liner of Temprel synthetic rubber and a partially protective sheath of stainless steel braid embedded during manufacture. Temprel maintains flexibility and strength at temperatures from -40°F to 300°F. The reinforced hose liner is then bonded to a full-coverage outer sheath of high-tensile stainless steel wire braid.
Max. Hose Oper.
Size I.D. O.D. Pressure
Pro-Lite 350 Hose
Max. Min.
Max. Hose Oper.
Size I.D. O.D. Pressure
Burst Pressure
Min.
Bend 3 Ft. 6 Ft. 10 Ft. 20 Ft.
Radius Part No. Part No. Part No. Part No.
Clamp Pressure
Bend 3 Ft. 6 Ft. 10 Ft. 20 Ft. Radius Part No. Part No. Part No. Part No.
-4
7/32"
7/16"
1500
250
2"
—
—
—
EAR420004ERL
-16
7/8"
1-5/32"
750
250
5.5"
EAR403016ERL
EAR406016ERL
—
—
-20
1-1/8"
1-7/16"
500
250
8"
EAR403020ERL
EAR406020ERL
—
—
Pro-Lite 350 Racing Hose is designed for use with Earl’s Swivel-Seal or Auto-Crimp hose ends. Hose is ultra lightweight, yet delivers superior durability and resistance to high temperatures. Save up to 30 lbs. when replacing the braided steel oil, fuel, and coolant hoses on a race car using a dry sump type engine. Abrasion-resistant nylon sheathing is bonded to the synthetic rubber liner’s textile inner braid for added durability.
-4
.22"
.44"
350
1400
2.00"
EAR350304ERL
EAR350604ERL
EAR351004ERL
EAR352004ERL
-6
.35"
.55"
350
1400
2.25"
EAR350306ERL
EAR350606ERL
EAR351006ERL
EAR352006ERL
-8
.44"
.65"
350
1400
3.50"
EAR350308ERL
EAR350608ERL
EAR351008ERL
EAR352008ERL
-10
.57"
.80"
350
1400
4.00"
EAR350310ERL
EAR350610ERL
EAR351010ERL
EAR352010ERL
-12
.69"
.94"
350
1400
4.50"
EAR350312ERL
EAR350612ERL
EAR351012ERL
EAR352012ERL
-16
.88"
1.16"
300
1200
5.50"
EAR350316ERL
EAR350616ERL
EAR351016ERL
EAR352016ERL
