Page 32 - 2022-23 Auto Performance Open Wheel Catalog

ENGINE
Engine Cover ALL26234 Water-repellent cover with bottom draw string is perfect for storage or transporta-
tion. 32" long x 23" wide x 28" tall.
Sprint Rear Motor Plate
ALL38126
CNC-machined black anodized aluminum rear motor plate fits standard and raised cam en- gines, standard and raised rail cars, as well
as newer style
lightweight blocks. Multiple holes are drilled and tapped for mounting pumps and torque ball shield directly to motor plate instead of the housing. The top trailing edge of motor plate is grooved to eliminate obstruction with dash. 3/8" thick plate weighs 7.25 lbs.
Bellhousing Dowel Pins
Steel dowel pins are approximately 1/2" longer than stock pins and are required when running an engine mid-plate, rear motor mounts, or an aftermarket bellhousing. These extended length pins also help with alignment when installing an engine. Pins fit most GM blocks and are sold in pairs.
Aluminum Sprint Motor Plates
Front motor plates for SB Chevy are offered in one and two piece de- signs. One piece versions mount using the lower front mounting holes. Two piece sets use the lower front mount holes and the water pump mounting holes. All plates have 19-1/2" center-to-center chassis mount- ing holes. ALL38128/38129 and ALL38145 plates come with bushings to allow for engine flex and help with weight transfer.
ALL38118
ALL38119
Finish
Part No.
ALL38145
Description
Thickness
ALL38118
1-Piece Solid Plate
Plain
3/8"
ALL38119
1-Piece Solid Plate
Black
3/8"
ALL38128
1-Piece Plate With Bushings *
Black
3/8"
ALL38145
2-Piece Plate With Bushings ‡
Black
3/8"
ALL38130
Universal Mount
Plain
1/4"
Part No. Description
ALL38152
* Has built-in mount for Saldana tank mount bracket OTMB-1. ‡ Designed to work with ALL36092 and ALL36093 tank mounts.
ALL38150
ALL38150
Solid Pins
ALL38152
Hollow Pins
ELECTRICAL, GAUGES, AND IGNITION
Brackets for Electrical Outlet
and Quick Disconnect
Steel bracket mounts to the chassis, providing a single convenient location to plug in an electrical outlet and a battery quick disconnect (ALL76320).
ALL60353
Battery Quick Disconnects
Disconnects provide a connection for battery charging, or for
quick battery changes during
a race. Prevent accidental
reverse polarity. Choose from 50 or 175-amp ratings. Sold in pairs and include cable terminals.
Part No.
Replacement Components
Natalie Klemko
Stan Kalwasinski
Part No.
Quick Disconnect Covers
Description
ALL60352
Weld-On Bracket
ALL60353
Bolt-On Bracket
Description
ALL76320
50-Amp Gray Disconnects, 1-Pair
ALL76322
175-Amp Red Disconnects, 1-Pair
Covers install over the end of the quick
disconnects to help prevent dirt and
debris from entering the connections.
Covers have a built-in lanyard to keep the cover close to con- nector and for easy assembly.
Part No. Description
ALL76321
6-Gauge Terminals for ALL76320, 1-Pair
ALL76323
2-Gauge Terminals for ALL76322, 1-Pair
ALL76324
Cover For 50-Amp Quick Disconnect
ALL76325
Cover For 175-Amp Quick Disconnect
