Water Pumps
Designed for racing and competition-proven, every Stewart pump is serial numbered, documented, pressure tested, and run-in at 10,000 RPM. We stock Stage 1, 2, 3, and the top-of-the-line Stage 4 pumps.
Stage 1 Water Pumps
Pumps use new original equipment iron castings that are machined and assem- bled to exacting standards. Pumps appear stock externally and may be used with stock lines and brack-
ets. Unlike stock pumps, the Stage 1 has a
precisely machined fan hub for perfect pulley alignment,
high-flow impeller, special water/anti-freeze compatible seal assembly, and, on some Stage 1 models, a severe-duty 3/4" ball/roller bearing. The Stage 1 has a full one-year warranty.
Stage 4 Water Pumps
Stage 4 pump incorporates all-new DRV-8 Series 8-Vane CNC-ma- chined billet 6061-T6 aluminum impellers and flows up to 41%
more water at twice the pressure
of traditional units, assuring equal
flow to left and right cylinder heads while
consuming less horsepower. Has all the same
features as Stage 3 Pumps, plus a full one-year warranty.
Part No. Description
Small Block Chevrolet
Pro Series Water Pump STE50005 Engineered exclusively for small block
Chevy racing applications, the Pro
Series water pump utilizes a twin
volute housing and replaceable
water pump cartridge, which
provides a perfectly balanced and
unsurpassed flow of coolant to both
sides of the block. Super-efficient
pump uses only two horsepower,
while delivering 50 GPM of flow.
Pump is 5.825" high, with a heavy-duty 3/4" shaft, 1/2" billet steel hub, -16AN side outlets, and stock mounting holes.
Performance Forged Pistons
SRP pistons, manufactured by JE, are “making
performance affordable”. SRP-specific forgings
eliminate several phases of the manufacturing
process, saving time and cutting costs with
high-volume production. All pistons are machined
to accept 1/16" top, 1/16" second, and 3/16" oil
rings. Sold in sets of eight, with wrist pins and
double Spiro Locks. Notes: Compression ratios based on the following combustion chambers: SB Chevy: 64cc
Part No.
Small Block Chevrolet
Stage 2 Water Pumps
Description
STE42200
Pre-1969 Short, 3/4" Shaft, Adjustable - (5.625")
STE42203
Pre-1969 Short, 3/4" Shaft - (5.625")
STE43103
1971-82 Corvette, 3/4" Shaft - (5.795")
STE12103
Pre-1969, Short, 5/8" Shaft - (5.625")
STE12203
Pre-1969, Short, Severe-Duty 3/4" Shaft - (5.625")
STE13103
1971-82 Corvette, Severe-Duty 3/4" Shaft - (5.795")
STE13113
1969-86 Long, 5/8" Shaft - (6.932")
Stage 2 pumps are inexpensive but very effective and include exclusive Stewart fea- tures like heat-treated, ribbed 356-T6 aluminum castings, extra-rigid cam
stops with exclusive 5/8" or 3/4"
ball/roller bearings, maximum-flow, close-tolerance nodular iron impellers, ma-
chined fan hubs with dual bolt patterns, and water/ anti-freeze compatible seal assemblies.
Part No.
Small Block Chevrolet
Description
STE22103
Pre-1969, Short, 5/8" Shaft - (5.625")
STE22203
Pre-1969, Short, Severe-Duty 3/4" Shaft - (5.625")
STE23103
1971-82 Corvette, 3/4" Shaft - (5.795")
STE23113
1969-86 Long, 5/8" Shaft - (6.932")
Professional Piston And Ring Kits
Revolutionary piston kits have
modern racing pistons with
low-friction metric ring sets. Kits
include lightweight forged side
relief (FSR) pistons, wrist pins
with carbon steel wire locks, and
JE Pro Seal premium piston ring set, complete with 1.2mm premium steel top rings, 1.5mm Napier second rings, and 3.0mm standard tension oil rings. Note: Compression ratios are based on the following combustion chambers: SB Chevy: 64cc
Bore Rod Dish/Dome Comp. Comp. Part No. Size Stroke Length Volume Height Ratio
Small Block Chevy
Bore Part No. Size
Stroke
Rod Length
Dish/Dome Volume
Comp. Height
Comp. Ratio
Small Block Chevy
High-Compression Domed Pistons
SRP140678
4.030"
3.480"
6.000"
11cc
1.260"
12.9:1
SRP140348 *
4.030"
3.750"
6.000"
7cc
1.125"
12.9:1
SRP140679
4.040"
3.480"
6.000"
11cc
1.260"
13.0:1
SRP140349 *
4.040"
3.750"
6.000"
7cc
1.125"
12.9:1
SRP140680
4.060"
3.480"
6.000"
11cc
1.260"
13.0:1
SRP140350 *
4.060"
3.750"
6.000"
7cc
1.125"
13.0:1
SRP142021
4.155"
3.750"
5.700"
4cc
1.425"
12.9:1
SRP142024 *
4.155"
3.750"
6.000"
4cc
1.125"
12.9:1
SRP142035
4.165"
3.480"
6.000"
9cc
1.260"
13.0:1
SRP142025 *
4.165"
3.750"
6.000"
4cc
1.125"
12.9:1
* Oil rail supports included.
High-Compression Domed Pistons
SRP271058
4.030"
3.750"
6.000"
7cc
1.125"
12.9:1
SRP271059
4.030"
3.480"
6.000"
11cc
1.260"
12.7:1
SRP271066
4.155"
3.750"
6.000"
4cc
1.125"
13.0:1
