Page 512 - 2022-23 Auto Performance Open Wheel Catalog

QUARTER MIDGET PARTS AND ACCESSORIES
DRIVETRAIN
Quarter Midget Belt-Drive Systems
Pulleys are machined from 6061 aluminum and have a black hard-coat finish. They are extremely
lightweight and wear-resistant. There are 4 engine pulleys and 13 axle pulleys to choose from; see gearing
chart for available ratios. Engine pulleys are designed to fit a standard 3-bolt engine hub and axle pulleys are
designed to fit a standard 4-bolt axle drive hub. It is recommended that the axle pulley be bolted directly to the axle hub.
Systems offer several advantages over common chain drives: Belt drives are lighter and can save up to 3 pounds of rotating weight.
Belt drives are very reliable and forgiving. They are more apt to stay on under contact for fewer DNF. Systems are much cleaner and require almost zero maintenance compared to chain drives.
Part No.
Description
Honda Gear Ratio Chart
Engine Pulley
HTD Drive Belts
65
58
53
51
38
3.51
3.93
4.30
4.47
39
3.60
4.03
4.42
4.59
40
3.69
4.14
4.53
4.71
41
3.78
4.24
4.64
4.82
42
3.88
4.34
4.75
4.94
43
3.97
4.45
4.87
5.06
44
4.06
4.55
4.98
5.18
45
4.15
4.66
5.09
5.29
46
4.25
4.76
5.21
5.41
47
4.34
4.86
5.32
5.53
48
4.43
4.97
5.43
5.65
49
4.52
5.07
5.55
5.76
50
4.62
5.17
5.66
5.88
JRP640-20HD
HTD Drive Belt, 20mm x 25.197"
JRP656-20HD
HTD Drive Belt, 20mm x 25.827"
JRP680-20HD
HTD Drive Belt, 20mm x 26.772"
JRP696-20HD
HTD Drive Belt, 20mm x 27.402"
JRP736-20HD
HTD Drive Belt, 20mm x 28.976"
JRP720-20HD
HTD Drive Belt, 20mm x 28.346"
JRP776-20HD
HTD Drive Belt, 20mm x 30.551"
JRP784-20HD
HTD Drive Belt, 20mm x 30.866"
JRP800-20HD
HTD Drive Belt, 20mm x 31.496"
JRP840-20HD
HTD Drive Belt, 20mm x 33.071"
JRP880-20HD
HTD Drive Belt, 20mm x 34.646"
ELECTRICAL
Components For Deco
Part No.
Description
MSD8207
Blaster 2 Coil for Deco
MSD8232
CPC Coil for Deco
BRBB106
Battery for Deco 5.8" Long x 3.4" Width x 4.1" Height
SUSPENSION & BODY
Ignition Switches
Part No.
Description
QRP50-410
Micro Single Pole Switch, Waterproof
QRP50-500
Standard Single Pole Switch
QRP50-520
HD Switch with Flip-Up Cover
QuickTach LCD
Recall Tachometers
QuickTach automatically displays the highest RPM attained from the last race for 15 minutes after shut down. Digital LCD unit is enclosed in a waterproof aluminum case and has an easy- to-read 3/4" x 2-3/4" backlit display. Powered by a 9-volt battery. Tach includes mounting brackets.
Part No.
Description
Snap-In Rubber Valve Stems ALL44139 Economical rubber valve stems pull through wheel for
easy installation. Stem for .453" hole, 4-pack.
QRP611-099
White/Red with Checkered Flag
QRP611-100
Black
510
2022-23 PARTS AND ACCESSORIES
Axle Pulley
