21 Circuit Classic Wiring Harness This most widely used
customizable chassis har- ness adapts to almost any vehicle. This kit comes with as well as without
a preterminated GM
column-mounted
ignition switch con-
nector. Included with
the harness is a GM-
engineered fuse block and Painless mounting bracket, GM turn signal connectors, pre-wired plugs for the head- lights and dimmer switch, and each wire is printed with Includes circuits for:
28-Circuit Classic-Plus
Wiring Harness Versatile enough
to adapt to most
vehicles, this kit in-
cludes most all the
power accessory
circuits needed for your vehicle. Includes with the har- ness is a GM-engineered fuse block and Painless mount- ing bracket, GM turn signal connectors, pre wired plugs for the headlights and dimmer switch, and each wire is color codes.
• Air Conditioning/Heat
• Accessory/Cigarette Lighter • Backup Lights
• Brake Lights
• Charging
• Dome Light
• Electric Choke
• Emergency Flashers
• Fan Relay Power Source
• Fused Power Source
• Headlights
PWI10201 PWI10202 PWI10203
Pro Series
GM Keyed Column Harness Non-GM Keyed Column Harness Pickup Chassis GM Keyed Column Harness
• Horn Relay
• Ignition Coil
• Instrument Panel • Parking Lights
• Radio/Clock
• Starting
• Tail Lights
• Third Brake Light • Turn Signals
• Wipers
Description
GM Keyed Column Harness
Non-GM Keyed Column Harness
Pickup Chassis GM Keyed Column Harness Pickup Chassis Non-GM Keyed Column Harness
Includes circuits for:
• Air Conditioning/Heat
• Accessory
• Accessory/Cigarette Lighter • Accessory/Trunk Light
• Backup Lights
• Brake Lights
• Charging
• Cruise Control
• Dome Light
• Electric Choke
• Electric Fuel Pump
• Emergency Flashers
• Fan Relay Power Source • Fused Power Source
• Headlights
• Horn Relay
• Ignition Coil
• Instrument Panel
Part No.
Description
Part No.
PWI10101 PWI10102 PWI10103 PWI10104
NEW!
The Painless 23- and
25-circuit Pro Series
harness kits provide
everything needed to
properly wire any custom vehicle. Manufactured with over 25 GM factory-style connectors used on most 60’s to early '90’s GM switches, making the Pro Series harness features include LED ATC-bladed fuses which light-up when blown, 6-gauge charge wire with midi-fuse to handle today's high-amperage alternators, and front/rear grounding harnesses ensuring a well-grounded system. Many GM connectors, insulated and non-insulated butt splices, heat shrink, grommets, cable ties, ground straps, and cable tie clips are also included to make the installa- tion as simple as possible. Kits are available with either
12-Circuit Fuse Block
PWI30001
Use in addition to existing wiring, or as a starting point for a custom - ers, horn relay, terminals, anti-theft feature, and instructions. Pre-wired for the following circuits:
• Turn Signals
• Air Conditioning/Heat • Emergency Flashers • Brake Lights
• Coil (Anti-Theft)
• Dome Light
• Horn
• Radio
• Wipers
• Headlights • Electric Fan • Instruments
18 Circuit Fuse Panel PWI30003
Same as PWI30001 with extra circuits for power windows, door locks, and other optional accessories.
Add extra circuits to an existing
wiring system without overloading the wiring or the ignition switch. Choose a 3-circuit or a 7-circuit kit.
Part No
23 Circuit Pro Series Kits
Description
PWI10401 PWI10402 PWI10403 PWI10404 PWI10405 PWI10406
GM Keyed Column, Grommet Firewall Pass-Through
Key In Dash, Grommet Firewall Pass-Through
GM Keyed Column, Bulkhead Firewall Pass-Through
Key In Dash, Bulkhead Firewall Pass-Through
Truck Kit, GM Keyed Column, Bulkhead Firewall Pass-Through Truck Kit, Key In Dash, Bulkhead Firewall Pass-Through
25 Circuit Pro Series Kits
Part No.
PWI70114 PWI70118
Description
3-Circuit High Amp CirKit Boss 7-Circuit High Amp CirKit Boss
PWI10411 PWI10412 PWI10413 PWI10414 PWI10415 PWI10416
GM Keyed Column, Grommet Firewall Pass-Through Key In Dash, Grommet Firewall Pass-Through GM Keyed Column, Bulkhead Firewall Pass-Through
Key In Dash, Bulkhead Firewall Pass-Through
Truck Kit, GM Keyed Column, Bulkhead Firewall Pass-Through Truck Kit, Key In Dash, Bulkhead Firewall Pass-Through
