28 | | | Cooktops | | | 500 Series | | | Electric
500 Series 24" Electric
Cooktop General Properties
Knob material
Element Performance
Power of front left heating element Power of back left heating element Power of back right heating element Power of front right heating element Element Size
Dimension of front left heating element Dimension of back left heating element Dimension of back right heating element Dimension of front right heating element Technical Details
500 Series Black Frameless – NEM5466UC
Plastic
1 850 W 2 2 200 W 1 200 W 1 800 W 6" 8" 6" 7"
7 100 W 30 A 208‒240 V 60 Hz
No plug Electric
1/8" +4 1/3" x x 23" x x 20 1/5" 4 4 1/3" x x 22" x x 19 1/4"
2 1/4"
2" Watts
Circuit breaker
Volts
Frequency
Plug type
Energy source
Dimensions & Weight
Overall appliance dimensions (HxWxD) Required cutout size (HxWxD) Minimum distance from counter front Minimum distance from rear wall
Net weight
Optional Accessories
HEZ390210
8" AutoChef® pan for 6" element HEZ390220
9" AutoChef® pan for 7"
element HEZ390230
10" AutoChef® pan for 8" and 9" elements
24" 500 Series NEM5466UC
• 8" 2 2 200 W Element • 6" 1 850 W Element • Residual Heat Indicator
• Stainless Steel Color Knobs
24 lbs
