Page 9 - Catalpa
P. 9
N
M
BEDROOM 2 10'-0" X 9'-10"
CL POWDER ROOM 7'-1" X 3'-2"
DN BEDROOM 3 11'-0" X 12'-4"
CL MECHANICAL CL LAUNDRY CL MASTER BEDROOM 15'-0" X 12'-9"
BEDROOM 2 10'-0" X 9'-10"
BEDROOM 3 11'-0" X 12'-4"
MASTER BATHROOM 11'-6" X 6'-6"
CL LOWER LEVEL PLAN
N
T S BATHROOM 2 5'-0" X 7'-7"
N
T S S 5'-0" X 7'-7"
N
T S CL MECHANICAL CL LAUNDRY CL BATHROOM 2 FIRST FLOOR PLAN
CL LOWER LEVEL PLAN
N
N
CL CL UP UP duplex 1
