What's NeW fleet / traNsPortatIoN
aIr brake aNtI freeze
• Provides complete winter brake protection
• Dissolves ice on contact
• Prevents rust and corrosion; removes water from
system
• Easy pour spout
suPer hIgh outPut 7" rouNd flood lIght
• Heavy diecast aluminum body and diecast aluminum adjustable bracket
• Built for the toughest environments
• Powder coated body
• Sealed coated electronics
• Impact resistant polycarbonate lens / plus secondary lens cover
• 12" Shielded lead w/Deutch connector
• Military style breather vent
• Working Temp: -40° to +50C
• Dimensions: 7.28" x 7.48" z 3.13"
• Voltage: 12-24 VDC
• Watts: 90
• Lumen: 6,000
led auxIlIary WorklIght
• 3,080 lumens, flood beam pattern
• Polycarbonate lens and high tech composite housing
• 14 LEDs, 2 wire connection
• Stainless steel bolt and bracket
• Operating amperage: 12/24 VDC
• Dimensions: 4.80" diameter, 1.50" depth
led auxIlIary WorklIght
• 3,520 Lumens, flood pattern
• Powdered coated cast aluminum body
• 12" shielded, pinned cables
• Dimensions: 4.65" W x 6" H x 2.9" D
led strobe lIght
• 4 extremely powerful LEDs, state-of-the-art driving technology and cutting-edge optics to produce the brightest surface-mount LED lamp on the market.
• 8 User-selectable flash-patterns, including Single Flash (steady burn), Quad Flash, Staggered Flash
• Meets SAE Class 1 requirements
• Height: 1.25 inches
• Depth: 3/8 inches
• Width: 4.5 inches
• Rated Current: 0.5 amps max at 12/8V
Part No.
Description
Lumens
Voltage
3169
Round Work Light
6000
12-24VDC
Part No.
Description
7858
Case of 12 (32 oz. Bottles)
7876
Individual (32 oz. Bottle)
State of California Consumers
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
battery CrImP tools
• Heavy duty handles with cushion grips
• Multiple settings using simple, 2-finger adjustment knob
• No dies means 30% smaller head width and lower crimp pressure required
• Unlike hex crimp, triangle crimp applies even pressure on connectors with
no pinch corners
• Triangle shaped crimp for solid copper crimp of connector and cable
• Crimps all major brands of battery terminals, copper lugs, and splices
• For SAE/AWG gauge cable
Part No.
Description
Amps 12V/28V
Voltage
3184
LED Work Light
2.3/0.99
12 or 24
44617
Part No.
Size/Description
Length
44615
8 Ga - 1/0
16"
44617
8 Ga - 250 MCM
25"
Part No.
Lumens
Amps 12V/28V
Voltage
3193
3,520
2.3/0.99
12 or 24
hIgh outPut mINI flood lIght
• Compact square, high-output, LED work flood beam
• Power coated, die cast aluminum housing
• High impact polycarbonate lens
• Sealed coated electronics
• Includes stainless steel mounting bracket & hardware
• Dimensions: 3.54" x 4.6" z 1.91"
• Voltage: 12-24V
• Amp Draw: 12V-1.89A, 24V-0.99A
• Lumen: 1,600
3210
3212
Part No.
Description
Lumens
Voltage
Part No.
Description
3212
Square Work Light
1600
12-24V
3482
LED Strobe Light
3483
3210
Round Work Light
3483
Grille Mounting Bracket
WN-12
