What's NeW threaded fasteNers
flaNge bolts metrIC Class 8.8
• Zinc plated for corrosion resistance, serrated face
• Made of heat treated steel
• Minimum 120,000 P.S.I. tensile strength (800 N/mm2)
• Rockwell Hardness C26-34
• Meets DIN 6921 specifications
tIf-loCk self-loCkINg Washers
bolt seCurINg system
• Tightly secures the bolt/nut under the harshest conditions - vibration, temperature, chemical, etc.
• Reusable - can repeatedly be removed and reinstalled when necessary for access
• Can be used with lubrication - allows maximum torque to be applied to fastener so system reaches maximum/needed clamp load
• Creates impression marks without scoring the mating surface
• Fast and easy to install - comes in preassembled pairs
• Use Large Pattern washers with large or slotted holes, painted surfaces,
soft underlying materials, whenever a flange bolt is used or in place of a flat washer.
CarboN steel
• Zinc plated for corrosion resistance
• Made of SAE J-403-AISI 1042/1045 or similar high carbon steel
• Through hardened to minimum HRC46
• Operational Temperature Range: -20° to +200° C
staINless steel
• 316L austenitic stainless steel to ENI.4404
• Surface hardened
• Good acid resistance
• Operational Temperature Range: -160°C to +500°C
staNdard PatterN
fraCtIoNal
Self-Locking washers have cams on one side with a greater rise than the pitch of the bolt. In addition, they have radial teeth on the opposite side. The washers are installed in pairs, cam face to cam face.
When the bolt and/or nut is tightened, the teeth grip and seat the mating surfaces. The teeth lock the washers in place, allowing movement only across the face of the cams. The tension created makes the bolt/nut self-locking.
Diameter
M6
M8
M10
M12
Length
1.0
1.25
1.50
1.75
12mm
68449
16mm
68450
68458
20mm
68451
68459
68466
25mm
68452
68460
68467
30mm
68453
68461
68468
68472
35mm
68473
40mm
68454
68462
68469
68474
50mm
68475
Nuts
70066
70067
70068
70069
Bolt Hex Size
10mm
13mm
15mm
16mm
Flange Dia.
14mm
18mm
22mm
26.5mm
Nut Hex Size
10mm
13mm
15mm
18mm
metrIC Nuts
Class 10 flaNge (loCk)
• Zinc plated for corrosion resistance
• 150,000 P.S.I. tensile strength (1040N/mm2)
• Rockwell Hardness C26-36
• Prevailing torque type lock nut
• Resists severe vibration and shock loads
• Meets DIN6927, ISO 7044
Class 8 flaNge
• Black phosphate finish, smooth face
• Rockwell Hardness C24-30
• 120,000 P.S.I. tensile strength
• OEM on domestic and import vehicles
Class 8 flaNge
• Zinc plated finish, serrated face
• Rockwell Hardness C24-30
• 120,000 P.S.I. tensile strength
• OEM on domestic and import vehicles
flaNge
*Indicates New Item
Size
I.D. (in)
O.D. (in)
Part No. 316
Zinc-Plated Steel
Stainless Steel
#8
0.17
0.30
54635
14710
#10
0.21
0.35
54636
14711
#12
0.26
0.43
54637
14712
1/4
0.28
0.45
54638
14713
5/16
0.34
0.53
54639
14714
3/8
0.41
0.65
54640
14715
7/16
0.45
0.73
54641
14716
1/2
0.53
0.77
54642
14717
9/16
0.60
0.91
54643
14718
5/8
0.67
1
54644
14719
3/4
0.79
1.21
54645
14720
7/8
0.92
1.36
54646
1"
1.10
1.54
54647
1 1/8
1.24
1.85
54630*
1 1/4
1.35
1.91
54631*
1 3/8
1.47
2.17
54632*
1 1/2
1.59
2.30
54633*
Size
Flange
W.A.F. (MM)
Cl. 10 Zinc Pl.
Cl. 8 Phos.
Cl. 8 Zinc Pl.
M5-0.80
70065*
8
M6-1.00
70017
30003
70066*
10
M8-1.25
70018
30006
70067*
13
M10-1.50
70019
30007
70068*
15
M12-1.75
70020
70069*
18
M16-2.00
70021
24
*Indicates New Item
State of California Consumers
External radial teeth surface
Internal wedge- shaped surface
