Page 380 - 2018 Racecar Engineering Open Wheel Parts and Accessories Catalog

Standard Steering Gear SWE310-40110-235 Power Steering Pump
SWE306-40130-235 SWE306-10300
Lightweight and All-new power steering pump, designed
compact, sprint exclusively for sprint car applications,
power steering features a fully CNC-machined billet 7075
box includes a 4130 chrome moly steel housing aluminum housing that is fitted with precision
that is fitted with billet 7075 aluminum side bells and | ground, high grade steel shafts and gears for
a gun drilled Pitman shaft, resulting in a unit that weighs optimum pressure. Unit is sold complete with
just 24 lbs. Half length box is designed for left hand drive applica- necessary fasteners and spacers.
tions. Reservoir tank must be purchased separately. Boxes may be Part No. Description
special ordered for left or right hand drive in full or half length. Replacement Parts
SWE321-41043 Shaft
RESERVOIR TANK SWE306-30070 SWE321-81010 Seal Kit For Pump
Plain power steering reservoir tank is specially designed
for use with the SWE306-40130-225 steering gear. Aluminum Quick Release
Steering Wheel Hub SWE801-70035
RESERVOIR TANK SWE306-30072
Aluminum quick release, splined shaft steering
Power steering reservoir tank clamps directly to the left
chassis tube. Black anodized finished and laser engraved wheel hub is designed specifically for sprint car
chassis fitted with KSE power steering.
with the Sweet logo.
Wing Valve SWE306-10100 Mini Sprint Rack
Manufactured from forged aluminum, two-way
control valve is compact and lightweight.
Valve includes integral mounting bosses and
is sold complete with fittings.
Part No. Description
SWE033-27114 2-3/4" Ratio With Clevis Ends
Wing Cylinders SWE033-47114 4-3/4" Ratio With Clevis Ends

Steering Wheels
Specifically designed to endure the rigors of sprint car racing. Flat style aluminum steering wheels.
Rigid, aluminum bodied hydraulic wing cylinder is fitted with a steel
piston and pushrod assembly, while heavy duty bushings and seals Part No. Description
eliminate any possibility of leakage. Standard - Coated Wheels
SWE601-70131 13" Flat Aluminum Wheel
Part No. Description
SWE306-10210 8" SWE601-70151 15" Flat Aluminum Wheel
SWE306-10200 10" SWE601-70171 17" Flat Aluminum Wheel
SWE306-10215 12" Standard - Uncoated Wheel
Cylinder Seal Kit SWE611-70131 13" Flat Aluminum Wheel
SWE331-43040 Seal Kit SWE611-70151 15" Flat Aluminum Wheel SWE601-70131
Replacement Shafts
SWE331-44013 8" Shaft
SWE331-44005 10" Shaft SWE331-44007
SWE331-44014 12" Shaft Flat Steering Wheel Pad
Replacement Fittings SWE601-70100
SWE331-44012 #3 Male To #3 O-Ring
Rod End And Cap Available for flat or dished steering wheels.
SWE331-44002 Cylinder Cap These pads provide added driver protection.
SWE331-44007 Wing Valve Handle
SWE331-44004 Cylinder Piston
Combination Fuel And
Power Steering Pump
This newly designed combination
assembly features a fuel pump that Power Steering Fluid
doesn't require a clamp and is nearly
two inches shorter than previous Formulated using the highest quality base oils
models. and additives available and then custom blended
SWE306-20400 to withstand extreme racing conditions.
Part No. Description
Part No. Description
Sprint Car Combination Assembly
SWE306-20400 SWE301-30090 1-Quart
With 400 Series Waterman Pump
Sprint Car Combination Assembly SWE301-30091 1-Case, (12-Quarts)
SWE306-20500
With 500 Series Waterman Pump
Replacement Fuel Pumps
SWE308-20400 Sprint Fuel Pump, Fits SWE306-20400
SWE308-20500 Sprint Fuel Pump, Fits SWE306-20500
379
