SportComp Shaft Roller Rockers Shaft Roller Rocker Arm Systems
High quality, affordable Extruded 2024 aluminum rocker
rocker sets reduce arms are CNC-machined, with in-
valve train weight tricate oil galleries to direct oil from
and valve lash the pushrod to the shaft bearings
adjustments while and onto the roller tip. Adjuster
increasing RPM potential. screws are 7/16" and broached for
System eliminates stud girdles a 3/16" socket to eliminate twisted
and provides better head bolt accessibility. Allen wrenches. Deep, case
Sets of 16 include all installation hardware. hardened 8620 steel shafts are
Part No. Description tempered for strength.
TDM10000-150/150 SB Chevy, 1.5/1.5 Rocker Ratio Int. Exh.
Part No. Application Ratio Length Offset Offset
TDM10000-160/150 SB Chevy, 1.6/1.5 Rocker Ratio Dart Sportsman II
TDM10000-160/160 SB Chevy, 1.6/1.6 Rocker Ratio TDM2144-160/150 Aluminum/Pro 1 1.6/1.5 1.450" .250" .170"
TDM10001-150/150 SB Chevy, .220" Offset, 1.5/1.5 Rocker Ratio TDM2144-160/160 Dart Sportsman II 1.6/1.6 1.450" .250" .170"
TDM10001-160/150 SB Chevy, .220" Offset, 1.6/1.5 Rocker Ratio Aluminum/Pro 1
TDM2150-160/150 Dart Iron Eagle 1.6/1.5 1.450" .170" .170"
TDM10001-160/160 SB Chevy, .220" Offset, 1.6/1.6 Rocker Ratio
TDM2217-160/150 Brodix ASCS 1.6/1.5 1.450" .375" .080"
TDM10020-160/160 SB Ford, 1.6/1.6 Rocker Ratio TDM2251-160/150 Brodix Track 1 Spec. 1.6/1.5 1.450" .250" .080"
TDM2251-160/160 Brodix Track 1 Spec. 1.6/1.6 1.450" .250" .080"
TDM2251-165/155 Brodix Track 1 Spec. 1.65/1.55 1.450" .250" .080"
TDM2251-165/160 Brodix Track 1 Spec. 1.65/1.6 1.450" .250" .080"
Deluxe Pinion TDM2301-150/150 AFR 227/235 1.5/1.5 1.450" .375" .080"
Depth Checker TDM11001 TDM2301-160/150 AFR 227/235 1.6/1.5 1.450" .375" .080"
TDM2301-160/160 AFR 227/235 1.6/1.6 1.450" .375" .080"
Set up rear ends quickly and
correctly. Fixture sits in place of
differential carrier to easily TDM03210
check pinion depth. Includes TDM03150
adapters for most popular Part No. Description
domestic rear ends. Replacement Parts
TDM03150 Rocker Arm Adjuster, 7/16"-20 x 1.130" With Shoulder, 5/16" Dia. Cup
TDM03210 Rocker Arm Jam Nut, 12 Pt., 7/16"-20 Thread
TDM05051 Hold Down Stud, 5/16"-18/24 x 1.890" With Starter
TDM05120 Hold Down Nut, 12 Pt, 5/16"
Rocker Arm Stand Bolt 7/16"-14 x 1-1/4",
TDM05220
12-Pt. 7/16” Flange Head Bolt
TDM05350 SB Chevy Stand Shim, .060", Thick
TDM05360 SB Chevy Stand Shim, .030", Thick
TDM05400 SB Chevy Stand Shim Kit, (8) .030" and (8) .060", Thicknesses

Oil Filter Relocation Kits TRA3300
Carburetor Stud Kits CNC-machined from billet 6061-T6 aluminum,
single remote filter units provide cleaner oil, add
Includes four each: studs, nuts and washers.
capacity, and increase flow with large, -12AN
Part No. Description ports. Use with Fram PH8A or equivalent oil filter.
TRA2046 Carb Stud Kit, 1-3/8" Long x 5/16" Coarse/Fine Thread
TRA2047 Carb Stud Kit, 2" Long x 5/16" Coarse/Fine Thread
TRA2106 Carb Stud Kit, 3" Long x 5/16" Coarse/Fine Thread
Spin-On Oil Filter Bypass Adapters
Adapters spin on in place of the stock oil filter.
Inlets and outlets are threaded 1/2" NPT. Use
Holley Carburetor Mount bypass adapters for plumbing remote filters.
Throttle Return Kit TRA2083 Part No. Description
Spring kit with chrome bracket mounts to TRA1013 Ford V8, Chrysler V8 3/4"-16 Threads,
all Holley 2300/2305 and 4150/4160 series 2-1/2" ID And 2-3/4" OD O-Ring
SB And BB Chevy 13/16"-16 Threads,
carburetors. Includes heavy and light springs. TRA1022
3-3/16" ID And 3-7/16" OD O-Ring
Remote Oil Filter Brack ets Billet Oil Filter Bypass Adapters
Cast alu mi num remote oil filter brackets have Aluminum spin-on adapters have large, -12AN
1/2" NPT inlets and out lets. ports for superior oil flow. Hose and fittings not
Part No. Description included.
Single Remote Bracket, Vertical Inlet And Outlet,
TRA1028 Part No. Description
3/4"-16 Nipple Accepts Fram PH8A Ford Filters Chevy V8, 13/16"-16
Single Remote Bracket, Horizontal Inlet And Outlet, TRA3321
TRA1045 And 3-3/16" ID And 3-7/16" OD O-Ring
3/4"-16 Nipple Accepts Fram PH8A Ford Filters
381
