Page 794 - BIC GRAPHIC 2017

PRINT MARGIN
(any objects NOT intended to bleed MUST be inside this print margin)
PRINT MARGIN
(any objects NOT intended to bleed MUST be inside this print margin)
Magnets
IMPRINTS
Color Matching
Bleeds
There is no extra charge for bleeds. Art intended to print to the edge must extend 1/16" outside the cut line. On Picture Frame Magnets, the inner cut-out artwork should bleed 1/16" onto the outer frame.
Magnetsareprintedwith4-colorprocessinksasopposedtospotcolorinks. MAGNET The 4-color process allows you to print as many different colors as you want for
one price. All non-standard imprint colors will be converted to the closest 4-color
process match. A perfect match cannot be guaranteed. Standard imprint colors are
shown on page 777.
When requesting a non-standard imprint color, please provide the color number or a color sample (swatch or photograph). Please note that when referencing a non- standardcolornumber,wematchtothenon-standardcolornumbercoatedcolor
values. When color is critical, we recommend a product proof. Please submit files in
1/16"bleed
die cut outline
LIVE (or text) AREA is 1/16” from cut line
area for text
1/8" border * *
the CMYK color mode only. RGB files will be converted to 4-color process (CMYK), which may result in color shifts. Raster images (digital photos) should be at least 300 DPI at 100% final size. Due to the digital artwork printing process, using placed raster or photograph images limits our ability to make color corrections.
Minimum Line Weights & Type Sizes
Text can be as small as 6 point on most fonts. Lighter fonts may need to be larger. Lines must be at least .5 point thick ( ). Reversed lines must be at least 1 point
Layout LIVE (or text) AREA area for text 3/8" border * * is 1/4" from cut line
thick ( ).
Screens
When a file contains a screen, it must be at no less than 10%. Anything less will
not print properly.
Borders
Borders are not recommended along the edges of Magnet products. However, art intended to print as a border must be formatted 1/16" inside the die line and extend 1/16" beyond the die line.
Standard packaging for MGDEM1 and MGDEM2 is a master carton with a box
MOUSEPAD
die cut outline
**borders must be 1/16" thick inside cut line & have 1/16" bleed
NOTE: template lines for production purposes only; they will not be printed
Personalization
Available on Magnets for $0.79(g) per name.
1/8" bleed
Always provide a layout and a hard copy of your art so that we will know how you want your magnets to look. There is a 1/16" variance on all magnets when cutting
**borders must be 1/4" thick inside cut line & have 1/8" bleed
the final product. Provide a color composite of multicolor images when sending in production-ready art or send it in color, digitally (VECTOR ART preferred). If color
NOTE: template lines for production purposes only; they will not be printed
matching is critical, a product proof is recommended.
Packaging
clip
Background image
DIGITAL size/bleed area limit Imprint Area Limit
BIC® Magnet Diagrams
MGSSS
Apple 1-7/8" x 2-1/8"
Octagon 1-3/4" x 1-3/4"
MGSSM
Awareness Ribbon 2" x 3-3/4"
Cell Phone 1-1/2" x 4-1/16"
Bandage 3-1/2" x 1"
Paint Brush 3" x 1-1/3"
Awareness Ribbon Business Card
3 -15/16" x 2-7/16"
Church 2-3/4" x 3-1/2"
Cell Phone/PDA 1-1/2" x 3-1/4"
Rectangle 1 3" x 1"
Bandage 2 3-1/4" x 1-5/8"
Circle 4 3" Diameter
Circle 1 2" Diameter
Square 1 1-1/2" x 1-1/2"
Bone 3-1/2" x 2-1/8"
Computer 3-3/8" x 2-1/2"
Circle 2 2-1/2" Diameter
Square 2 2" x 2"
Business Card w/Bite 3-1/2" x 2"
Cup 4-1/2" x 2-3/8"
Circle 3 2-3/4" Diameter
Tooth 1-3/4" x 2-1/2"
Capsule 3-5/16" 1-5/8"
Dollar Sign 2-1/2" x 3-1/4"
Cylinder 1-1/2" x 2-1/2"
Tube 3-1/2" x 1-1/4"
Car 4-1/4" x 1-1/2"
Drop 2" x 3"
House 2-3/4" x 1-3/4"
of dry-erase magnets, a box of whiteboard markers and a separate bag of clips. Optional packaging to polybag one dry-erase magnet, one marker and one clip together is $0.39(g) per polybag. clip
Proofs DIGITAL GRAPHICS
For Custom Shape Magnets, please allow 3 working days for a fax proof. Product
proofs are available. Die charge applies; please call your distributor for quote.
Outdoor Use
All magnets are not recommended for outdoor use or for use on cars.
Custom Die Shapes
We will stock your custom dies at no extra charge for a maximum of 24 months from last use.
Cat 2-1/2" x 3"
Flag 3-1/4" x 2-3/4"
MGSSM (continued)
792 bicgraphic.com
Football 3-1/2" x 2-5/16"
Hand 3-3/8" x 2-1/4"
Heart 3" x 3"
House
4" x 2-9/16"
Key 3-3/4" x 1-7/8"
Light Bulb 2-3/8" x 3-3/8"
Lightning Bolt 2" x 3"
CAD $
Mortar & Pestle 2" x 2-5/8"
