 TOOLS & PIT EQUIPMENT
  Toe Plates
Ride Height Set-Up Stick ALL10658 Stick replaces the coil-over shock and spring
assembly during maintenance. Stick has many uses and may be adjusted to check settings at normal ride height, in race attitude, or on the bump stops to eval- uate suspension travel. Adjusts
from 15" to 24", measured at the center of rod ends.
Set-Up Tool ALL10668
Tool replaces the front coil-over shock assembly to
simulate range of front suspension movement for checking bump steer and roll center. Hex-head threaded shaft raises and lowers suspension to simulate racing conditions. Jam nuts can be positioned to limit rebound and compression. Not designed to support total vehicle weight, only suspen- sion components.
Set-Up Plates
ALL10660
ALL10662
Set-up plates are used for squaring and stringing chassis to ensure accurate chassis set-up by eliminating wheel and tire differences. Plates are 1/2" thick and can also be used when setting bump steer or checking axle tubes for straightness. Sold each.
Aluminum plates simplify
setting of toe-in and toe-out.
    -
es of tires. Using two tape
measures (sold separately),
measure the distance front
and rear, between plates. The
difference in tape readings is
the toe setting. Deluxe plates
have radiused edges, slots
for narrow and wide tape
measures and are 9" tall x 23" wide to work with vehicles with smaller wheel openings. Standard plates are 1/2" thick, 11" tall x 32" wide and work well for vehicles with larger wheels and wheel openings. Set of two plates.
ALL10117
ALL10119
  Part No.
ALL10117 ALL10119
Description
Standard Deluxe
   16' Tape Measure
ALL10675
16' x 3/4" blade has fractional markings every 1/8" for quick reference.
Caster Kit
Measure your front end caster by attach- ing an adapter and level holder to your upper ball joint threads. Additional adapt- ers may be purchased separately for other use. Digital level sold separately.
   Part No.
Description
 ALL11162
Kit with Holder, BJ Adapters and Carry Case (No Digital Level)
ALL11164
Holder Only for Digital Level
ALL11165
Quickchange Pinion Angle Adapters (2)
ALL11166
Late Model Spindle Adapter
ALL10742
2x2 Digital Level
Caster Plate ALL10752
Not sure if you turned your wheels the same
Part No.
ALL10660 ALL10662
Description
5x5, 7" x 28" Wide 5, 12" x 28"
  amount each time when adjusting caster
settings on your race car? Unless you have
expensive turn plates, you’re never certain,
until now. This quick-reference gauge positions
under the upper ball joint nut, with markings facing up, for easy viewing. Place a mark on the shock body or fabricate an indica- tor to use as a reference point.
  Ground Clearance Indicator
ALL10725
Determine how close the frame is to the ground on the race track. This unique kit features an aluminum bracket that rivets to the frame with an adjustable 4" plastic wear rod.
Replacement Part
Part No. Description
ALL10726 Wear Rods, 4-Pack
Upper Ball Joint Wrench
ALL11190
Wrench is designed to
remove and install common screw-in upper ball joints that are 1.900" wide (ALL56214).
Bolt Center Caps ALL10678 Caps slip over the head of standard
1/2" bolts to accurately measure the
center-to-center length of installed sus-
pension tube assemblies. Machined step
secures the end of a standard tape measure for easy reading of the length to the center of the opposite cap. Caps feature a built-in O-ring that allows the cap to swivel on the bolt head and keeps it from falling off. Package of 2.
