P. 172

 Valve Stem Puller ALL44032 Puller threads onto
valve stem and properly pulls rubber valve stems
into place. Large rubber block protects expensive wheels and creates leverage when pulling.
Valve Core Tool ALL44030 Easily remove and install new valve cores.
Base of handle has a machined pattern to aid with grip. Ergonomically designed and crafted from stainless steel. Mea- sures 3" overall length.
Brass Valve Stems
Brass bolt-in valve stem resists cutting during contact. Sold each.
Snap-In Rubber Valve Stems
Economical rubber valve stems pull through wheel for easy installation. Large stem for 5/8" hole is the most popular size valve stem used in racing wheels. Smaller stem for .453" hole is commonly found in stock steel and utility vehicle wheels.
WHEEL AND TIRE ACCESSORIES
  Part No.
ALL44136-50
Description
Stem for 5/8" (.625") Hole, 50-Pack
 ALL44136
Stem for 5/8" (.625") Hole, 4-Pack
 ALL44139
Stem for .453" Hole, 4-Pack
  Part No.
ALL44134 ALL44135
Description
Brass Valve Stem. Fits .625" Hole
Chrome Plated Brass Valve Stem. Fits .453" or .625" Hole
Flush Mount Valve Stem Kit ALL44137
stem mounts in standard valve stem location and provides a clean semi-      an O-ring to seal against the outside of the wheel and a rubber grommet, washer, and nut that seals against
the inside of the wheel. Kit includes

Valve stems are designed for use in wheels with .453" valve stem holes.
  Replacement Parts
  Part No.
ALL99150 ALL99151
Description
Valve Core, 10-pack Valve Stem Caps, 10-Pack
Replacement Part
Part No.
ALL44138
PHIL AUSRA
  Description
Replacement Filler Tube
     2-1/2" Coil-Over Kits
Made of aluminum, these kits have slotted tops and are available for Carrera/QA1, Koni, Pro-Shock, Bilstein, and others.
  Part No.
Description
 AAA12420
Pro Shock 5" Coil-Over Kit
AAA12425
Pro Shock 7" Coil-Over Kit
AAA12432
Koni 5" 30 Series Coil-Over Kit
AAA12433
Koni 7" 30 Series Coil-Over Kit
AAA12435
Bilstein 5" Series Coil-Over Kit
AAA12436
Bilstein 7" Coil-Over Kit
 Replacement Components
AAA12450
5" Aluminum Sleeve, Carrera/QA1, Pro
AAA12455
7" Aluminum Sleeve, Carrera/QA1, Pro
AAA12460
Aluminum Adjusting Nut
AAA12465
Slotted Coil Top, Carrera/QA1, Bilstein
AAA12490
Hairpin Clip
AAA12495
Snap Ring
Suspension Tubes
Gold-anodized aluminum tubes are threaded RH on

one end.
Part No. Length
Part No.
Description
  12000 Series:
 7/8” Dia. x .156” Wall, Tapped 5/8” RH and LH
 AAA12000-12
12"
AAA12000-13
13"
AAA12000-14
14"
   Unthreaded 6' Lengths to Make Your Own Tubes
AAA12050-72
1" Diameter with .225" Wall for 5/8" Heims
 Rod End Bushings
Bushings reduce the diameter of the mounting hole for rod end bolt. Sold individually.
Part No. Size
Reducer Bushing Assortment AAA10480 Assorted sizes, (10) pieces
Aluminum Wheel Adapters
Adapter allows use of Wide 5 or mod-

circle hubs and rear ends. Available for the following hub bolt circles:
Part No. Description
   AAA10460
1/2" to 3/8"
AAA10465
5/8" to 1/2"
AAA10470
3/4" to 1/2"
AAA10475
3/4" to 5/8"
 AAA12800
4-1/2" Bolt Circle
AAA12805
4-3/4" Bolt Circle
AAA12810
5" Bolt Circle
AAA12815
5-1/2" Bolt Circle
170 TRACK
CIRCLE 2021-22
