P. 247
SZ Series Steel Shock Absorbers
SZ Series digressive-valve, monotube gas shocks are
-
Shock Absorber Package BILDP1
the guesswork out of ordering the - - sive and linear valve monotube gas,
Part No. Description
SL Series
Steel Shock Absorbers
consistent, fade-free performance. Shocks are available
Part No.
Length
Length
Stroke
Damping
Damping
Extended Compressed
Rebound Compression
BILF4-B46-0210-ZD 20.00" 13.14" 7" 80 lbs. 600 lbs.
BILF4-B46-0210-YA 20.00" 13.14" 7" 160 lbs. 160 lbs.
BILF4-B46-0210-ZB 20.00" 13.14" 7" 160 lbs. 210 lbs.
BILF4-B46-0210-ZE 20.00" 13.14" 7" 160 lbs. 260 lbs.
BILF4-B46-0210-ZC 20.00" 13.14" 7" 160 lbs. 320 lbs.
BILF4-B46-0210-ZZ 20.00" 13.14" 7" 185 lbs. 160 lbs.
BILF4-B46-0210-ZV 20.00" 13.14" 7" 185 lbs. 235 lbs.
BILF4-B46-0210-ZX 20.00" 13.14" 7" 210 lbs. 210 lbs.
BILF4-B46-0210-ZR 20.00" 13.14" 7" 235 lbs. 290 lbs.
BILF4-B46-0210-ZN 20.00" 13.14" 7" 260 lbs. 160 lbs.
BILF4-B46-0210-ZW 20.00" 13.14" 7" 260 lbs. 260 lbs.
BILF4-B46-0210-ZG 20.00" 13.14" 7" 290 lbs. 290 lbs.
BILF4-B46-0210-ZH 20.00" 13.14" 7" 320 lbs. 120 lbs.
BILF4-B46-0210-YD 20.00" 13.14" 7" 320 lbs. 210 lbs.
BILF4-B46-0210-ZT 20.00" 13.14" 7" 320 lbs. 320 lbs.
BILF4-B46-0210-ZY 20.00" 13.14" 7" 380 lbs. 160 lbs.
BILF4-B46-0210-ZU 20.00" 13.14" 7" 380 lbs. 235 lbs.
BILF4-B46-0210-ZS 20.00" 13.14" 7" 380 lbs. 320 lbs.
BILF4-B46-0210-ZF 20.00" 13.14" 7" 500 lbs. 210 lbs.
BILF4-B46-0210-ZM 20.00" 13.14" 7" 500 lbs. 320 lbs.
BIL33-239569 23.44" 14.94" 9" 120 lbs. 210 lbs.
BIL33-239514 23.44" 14.94" 9" 120 lbs. 320 lbs.
BIL33-239508 23.44" 14.94" 9" 120 lbs. 500 lbs.
BILF4-B46-0207-YA 23.44" 14.94" 9" 160 lbs. 160 lbs.
BILF4-B46-0207-ZE 23.44" 14.94" 9" 160 lbs. 260 lbs.
BIL33-239538 23.44" 14.94" 9" 160 lbs. 320 lbs.
BILF4-B46-0207-ZZ 23.44" 14.94" 9" 185 lbs. 160 lbs.
BILF4-B46-0207-ZA 23.44" 14.94" 9" 210 lbs. 80 lbs.
BILF4-B46-0207-ZP 23.44" 14.94" 9" 210 lbs. 120 lbs.
BILF4-B46-0207-ZX 23.44" 14.94" 9" 210 lbs. 210 lbs.
BILF4-B46-0207-ZR 23.44" 14.94" 9" 235 lbs. 290 lbs.
BILF4-B46-0207-ZN 23.44" 14.94" 9" 260 lbs. 185 lbs.
BILF4-B46-0207-ZW 23.44" 14.94" 9" 260 lbs. 260 lbs.
BILF4-B46-0207-ZG 23.44" 14.94" 9" 290 lbs. 290 lbs.
BILF4-B46-0207-ZJ 23.44" 14.94" 9" 320 lbs. 80 lbs.
BILF4-B46-0207-ZH 23.44" 14.94" 9" 320 lbs. 120 lbs.
BILF4-B46-0207-YD 23.44" 14.94" 9" 320 lbs. 210 lbs.
BILF4-B46-0207-ZT 23.44" 14.94" 9" 320 lbs. 320 lbs.
BILF4-B46-0207-ZY 23.44" 14.94" 9" 380 lbs. 160 lbs.
DP1 Shock Absorber Package
BIL33-239491
Left Front Shock Absorber
BIL33-239477
Right Front Shock Absorber
BIL33-239552
Left Rear Shock Absorber
BIL33-239545
Right Rear Shock Absorber
Optional DP2 Shock Absorbers
BILDP2LF
Left Front Shock Absorber
BILDP2LR
Left Rear Shock Absorber
Part No.
Length
Length
Stroke
Damping
Damping
Extended Compressed
Rebound Compression
BILF4-BE5-F591-M0
20.00"
13.14"
7"
3
4
BILF4-BE5-F592-M0
20.00"
13.14"
7"
3
5
BILF4-BE5-F595-M0
20.00"
13.14"
7"
4
2
BILF4-BE5-F596-M0
20.00"
13.14"
7"
4
4
BILF4-BE5-F598-M0
20.00"
13.14"
7"
5
5
BILF4-BE5-F599-M0
20.00"
13.14"
7"
6
2
BILF4-BE5-F603-M0
23.44"
14.94"
9"
1.5
5
BILF4-BE5-F606-M0
23.44"
14.94"
9"
3
3
BILF4-BE5-F608-M0
23.44"
14.94"
9"
3
5
BILF4-BE5-F609-M0
23.44"
14.94"
9"
3
6
BILF4-BE5-F612-M0
23.44"
14.94"
9"
4
1.5
BILF4-BE5-F613-M0
23.44"
14.94"
9"
4
4
BILF4-BE5-F612-M0
23.44"
14.94"
9"
5
5
SZ Series
“COB” Steel Shock Absorbers
- consistent, fade-free performance. Specialized, “COB” digressive pistons with check valves installed on the com- pression side create less bleed and more damping force on the rebound side, particularly at low piston speeds. May be converted to coil-over application.
Extended Compressed
Part No. Length Length Stroke
Rebound Compression Damping Damping
BILF4-BE5-H922-M1
20.00"
13.14"
7"
10
2
BILF4-BE5-H923-M1
20.00"
13.14"
7"
12
2
BILF4-BE5-H919-M1
20.00"
13.14"
7"
7
2
BILF4-BE5-H920-M1
20.00"
13.14"
7"
8
2
BILF4-BE5-H921-M1
20.00"
13.14"
7"
9
2
