Page 494 - 2021-22 Auto Performance_Circle Track
P. 494
30 Series Steel Body Mono-Tube Shock Absorbers
Single-adjustable, mono-tube shocks have four distinct rebound adjustments to suit chassis set-up or track condi- tions. The 30 Series shocks feature induction-hardened, chrome-plated 9/16" piston rods, and each shock body has three grooves to accept a lightweight threaded coil-over sleeve (sold separately). Mount in any position and use as coil-over or non-coil-over.
Street Stock Oval Track Shock Absorbers
meet the rugged demands of oval track racing with heavy-duty
tune the chassis for existing track conditions.
Compression Rebound Minimum Part No. Valving Valving Length
5" Stroke Shock Absorbers
KON30-5325 3 2-5 10.75"
KON30-5436 4 3-6 10.75"
6" Stroke Shock Absorbers
KON30-6325 3 2-5 12.25"
KON30-6436 4 3-6 12.25"
7" Stroke Shock Absorbers
Maximum Length
15.75" 15.75"
18.25" 18.25"
19.75" 19.75" 19.75"
23.75" 23.75"
Year/Model
Front
KON8040-1087 KON8040-1087
KON8040-1087 KON8040-1087 KON8040-1087 KON8040-1087 KON8040-1087
—
KON8040-1087 KON8040-1087
KON8040-1087 KON8040-1087 KON8040-1087 KON8040-1087
KON8040-1087
Rear
KON8040-1088 KON8040-1088
KON8040-1018 KON8040-1088 KON8040-1088 KON8040-1088 KON8040-1088
KON8040-1026
KON8040-1088 KON8040-1088
KON8040-1088 KON8040-1088 KON8040-1088 KON8040-1088
KON8040-1088
KON30-7325 KON30-7436 KON30-7499*
3 2-5 12.75" 4 3-6 12.75" 4 9-9 12.75"
1974-79 Apollo/Skylark 1970-87 Regal/Grand National
Chevrolet
1970-81 Camaro 1977-91 Caprice/Impala 1964-85 Chevelle/Malibu 1970-87 Monte Carlo 1975-79 Nova
Ford
1979-93 Mustang (4 Cyl. Only)
Oldsmobile
1964-87 Cutlass 1975-79 Omega
Pontiac
1970-81 Firebird 1973-77 Grand Am 1969-87 Gran Prix 1978-81 LeMans 1975-79
Ventura II/Phoenix
9" Stroke Shock Absorbers
KON30-9325 3 2-5 14.75" KON30-9436 4 3-6 14.75"
* Spec. Shock absorber for ACT Late Model Series
2.5" Coil-Over Kit
KON30-0000
Coil-over kit is used with large top eye 30 series dampers with 2.5" I.D. springs.
Replacement Bearing
KON1425-50-00-13
Koni 30 Series shock absorbers.
Buick
Bump Rubber KON72-34-48-000-0
shock absorber and prevents the suspension
from bottoming out. Similar to a progressive
spring, bump rubber resistance increases as it is
compressed, providing controlled bottoming of the suspension. Prevents internal shock damage caused by metal-to-metal con- 14mm rod dia.
Note: The non-tapered end of the bump rubber may be trimmed to increase shock travel, if desired.
Part No.
KON8040-1018 KON8040-1026 KON8040-1087 KON8040-1088
Upper Lower Mount Mount
Fork Pin Pin Eye Pin Cross Bar
Fork I-Stud
Max. Length
20-3/8" 20-5/16" 13-3/4" 21-1/8"
Min. Length
12-7/16" 12-3/8" 8-7/8" 13-1/16"
Street Stock Oval Track
Koni Part Number System
30-53 2 Through 5
Series
Rebound Valve Range Stroke Compression
NEW VENDOR!
Part No.
KOKR300-10 KOKR35-35-10 *
Description
Race Series Muffler, 3" Inlet/3" Outlet Race Series Muffler, 3-1/2" Inlet/3-1/2" Outlet
* Spec. muffler for Stafford Motor Speedway (CT.).
