 ELECTRICAL, GAUGES & IGNITION
 Canister-Style Ignition Coil
ALL81234

ignitions has low primary resistance and 112:1 turn ratio for improved throttle response and more power         - ets or Allstar ALL81236 coil bracket.
Coil Mounting Bracket
ALL81324
Aluminum canister-style coil mounting bracket
                  secure coil in bracket before mounting.
Universal Coil Mounting Bracket ALL81326 Universal bracket is an OE-style bracket
that mounts canister-style coils to some popular V8 intake manifolds or may be           Bracket includes a tension screw to secure coil in bracket before mounting.
MSD/FAST Ignition Box Mount
ALL81330
Box mount provides a quick- release method for replacing MSD or FAST ignition boxes with 7-1/2" x 3-1/2" or 4-1/8" x 6-1/2" center to center mounting dimen- sions. Kit includes aluminum box mount, (4) quick turn fasteners, springs, and 1/8" aluminum rivets.
Ground Straps
The number one problem with
electrical systems is often related to
poor ground connections. Perfect for
various 6-or 12-volt grounding ap-
plications. Flexible, braided copper
12-gauge ground straps are 5/16"
wide and have 3/8" non-insulated ring terminals on each end.
Spark Plug Indexing Tool ALL96510 Indexing positions the ground
strap of the spark plug properly for
best piston dome clearance and
un-shrouds the electrode for a more even burn and possible            14mm spark plugs. Includes instructions.
Spark Plug Gap Tool ALL96515 Tool properly cradles the spark plug to
consistently set plug gaps using a standard feeler gauge. Insert plug
into holder, place desired thickness
of feeler gauge between ground strap and electrode then gently turn the knob until feeler gauge is snug.
Spark Plug Gap Tool Kit ALL96516 Spark plug gap tool
quickly and accurately
gaps 14mm threaded
spark plugs. Thread
spark plug into tool,
place the correct size
feeler gauge beneath
the ground strap then tighten knob to set plug
gap. Includes 17 different feeler gauge sizes .010" thru .035".
Spark Plug Race Wire Sets
Custom-length SBC wire sets feature 8mm spiral core race wire with pre-ter- minated ends and universal coil wire. Sets feature shrink sleeved ends and
Part No. Description
Universal Spark Plug Race Wire Sets
Universal length 8mm spiral core wire sets include a non-terminated end, ends, and boots for a build-to- length option.
         ALL81365
Set without Sleeving, under Header
ALL81366
Set without Sleeving, over Valve Cover
ALL81370
Set with Sleeving, under Header
ALL81371
Set with Sleeving, over Valve Cover
  Part No.
ALL76330 ALL76332
Description
9" Long 12" Long
Part No.
ALL81360 ALL81361
Description
Set with 90° HEI Ends Set with 135° HEI Ends
    Spark Plug Index Shims
Stackable shims index spark plugs
at 30° intervals up to 360°, properly
positioning ground strap in cylinder head for increased power and clearance between spark plug and piston. Shims are intended for use         of 24 shims contains 12 silver 60°, 12 black 90°, detailed instructions, and dial chart.
Coil Wire Kits
Kit includes 36" of 8mm spiral core race wire, ends, connectors, and wire stripping/ crimp tool.
 Part No.
ALL81380 ALL81381
Description
Kit without Sleeving Kit with Sleeving
  Part No.
ALL96505 ALL96506*
Description
Shim Kit, Standard O.D. (.800") Shim Kit, Small O.D. (.720")
Spark Plug Boot Sleeves
Fiberglass braided sleeves are heat resistant to protect spark plug boots from header heat up to 1,200°F. 7-1/2" long sleeves slide over a variety of boots.
Part No.
   Description
 ALL34272
Natural, 8-Pack
ALL34273
Natural, 2-Pack
ALL34274
Black, 8-Pack
ALL34275
Black, 2-Pack
*Shims are designed for close tolerance spark plug pockets such as those on ALL-PRO cylinder heads.
