Page 629 - 2021-22 Auto Performance_Circle Track
P. 629
Harmonic Balancer Installation Tools
Eases harmonic balancer installation.
PFM66519
GM LS Valve Spring Compressor Tool PFM67603
Valve spring compressor, designed for
to use, and works with common hand tools.
Stud Mount Valve Spring Com- pressor PFM66784
Quickly remove valve springs from assembled engines
Adjustable Ring Compressor
Tapered compressor eases piston instal- lation and is compatible with a range of bore sizes. More economical than single bore size compressors.
Part No.
Description
PFM66515
Harmonic Balancer Installation Tool, Most Domestic V-8’s
PFM66518
Harmonic Balancer Installer and Puller, GM LS NEW!
PFM66519
Harmonic Balancer Installation Tool, GM LS
PFM66520
Harmonic Balancer Installation Tool Kit, Includes 12 Adapters
PFM66522
Harmonic Balancer Installation Tool, Early Ford, Includes 5/8”-18 & 3/4”-16 Threaded Ends NEW!
PFM66525
Harmonic Balancer Installation Tool, 2004-Up Ford, M12 x 1.5, 6" Long NEW!
Digital Valve Spring Tester
PFM66776
Digital bench-top valve spring tester is the most accurate method to check spring pressure. Manufactured from precision-machined billet aluminum, unit includes a backlit digital display - automatic shut-off features.
Valve Spring Height Micrometer
PFM66902
Part No.
Description
PFM66766
Adjustable Ring Compressor, 4.000"-4.090" Bore
PFM66767
Adjustable Ring Compressor, 4.125"-4.205" Bore
PFM66768
Adjustable Ring Compressor, 4.205"-4.310" Bore
Billet Aluminum Piston Ring Squaring Tool
tool allows installing piston rings squarely in cyl- inder bore so that ring end gap may be measured precisely.
Part No.
Description
PFM67656
4.000"-4.230"
PFM67654
4.240"-4.380"
Measure valve spring height accurately on an
assembled engine. Install the micrometer in place
of valve spring and rotate the tool until the valve, retainer, and with most V-8’s.
Tall Valve Spring Height Micrometer for Beehive Valve Springs PFM67390
Adjustable height micrometer allows precise mea- surement of valve spring installed height in a range in place of the valve spring and follow by rotating the dial to expand the tool to seat the valve, retainer, and locks. Fits most engines with beehive valve springs.
Pneumatic Valve Spring Compressor
PFM66849
Ease cylinder head disassembly with pneu- matic valve spring compressor. Air-oper-
includes slides for adjustment, and a locking pin provides easy, rapid installation. Compatible with most popular cylinder heads.
Manual
Piston Ring Filer
File piston rings quickly and precisely.
Part No.
Description
PFM66785
Manual Piston Ring Filer
PFM66786
Replacement Carbide Wheel
6-Volt Electric Piston Ring Filer PFM66765
Powerful, rechargeable
6-volt battery-powered tool wheels and re-charger.
120-Volt Electric Piston Ring Filer NEW!
PFM66758
Manufactured from high-quality
-
grinding wheel.
CIRCLE 2021-22 627 TRACK
