Page 632 - 2021-22 Auto Performance_Circle Track
P. 632
“A” Series Aluminum Smooth Body Shocks
feel and ultimate traction. Fully rebuildable and revalvable, each shock is serial numbered, dyno tested, and sold complete with dyno sheet. Shocks include bearing ends. Simply purchase
Coil-Over Kits for “ACF” Series
Part No.
Description
PROC352
Coil-Over Kit, 2-1/2", Flat Spring Seat
PROC353
Coil-Over Kit, 2-1/2", Tapered Spring Seat
Part No.
Stroke
Collapsed Length
Extended Length
Damping Comp./Rebound
A wide variety of replacement hardware is offered for both aluminum and steel-body shock absorbers.
PROB200A PROB212 PROB212-1 PROWB200 PROC305
Part No. Description
PROA646B 6" 11.50" 17.50" 4/6
PROA650B 6" 11.50" 17.50" 5/5
PROA653B 6" 11.50" 17.50" 5/3
PROA740B 7" 12.50" 19.50" 4/4
PROA745B 7" 12.50" 19.50" 4/5
PROA746B 7" 12.50" 19.50" 4/6
PROA750B 7" 12.50" 19.50" 5/5
PROA751B 7" 12.50" 19.50" 5/1
PROA752B 7" 12.50" 19.50" 5/2
PROA754B 7" 12.50" 19.50" 5/4
PROA762B 7" 12.50" 19.50" 6/2
PROA763B 7" 12.50" 19.50" 6/3
PROA838B 8" 13.50" 21.50" 3/8
PROA846B 8" 13.50" 21.50" 4/6
PROA847B 8" 13.50" 21.50" 4/7
PROA848B 8" 13.50" 21.50" 4/8
PROA849B 8" 13.50" 21.50" 4/9
PROA939B 9" 14.50" 23.50" 3/9
PROA940B 9" 14.50" 23.50" 4/4
PROA945B 9" 14.50" 23.50" 4/5
PROA946B 9" 14.50" 23.50" 4/6
PROA947B 9" 14.50" 23.50" 4/7
PROA948B 9" 14.50" 23.50" 4/8
PROA950B 9" 14.50" 23.50" 5/5
PROA956B 9" 14.50" 23.50" 5/6
PROA957B 9" 14.50" 23.50" 5/7
PROA960B 9" 14.50" 23.50" 6/6
PROB200A
Aluminum Bearing End, 2" Body Coil-Over Shocks, 1/2" I.D. Hole
PROB212
Standard Billet Rod End, ACF Shocks
PROB212-1
1" Extended Billet Rod End, ACF Shocks
PROB275
Aluminum Bearing End, 1.63" Body Coil-Over Shocks, 1/2" I.D. Hole
PROC305
Coil-Over Snap Ring, 2" Body Shocks
PROC510
1" Shock Extension
PROC520
2" Shock Extension
PROS500
Eye Ring, Screw-On with 1/2" Sleeve
PROS506
Stud Mount, Straight Threaded Stem-Type Shock End
PROS512/514
GM Bar Pin Assembly, 9/16"
PROWB200
Steel Bearing End, 2" Body Coil-Over Shocks, 1/2" I.D. Hole
PROZ902
Spanner Wrench, Allows Easy Coil-Over Adjustments
AFC10157
Large Diaper Pin
Coil-Over Kit PROC300
"ASB" Series Aluminum Small Threaded-Body Shock Absorbers NEW!
Smooth-and threaded-body, twin tube aluminum shock absorbers are engineered to offer superior driver O.D., and are hand-built, serial numbered, and dyno tested. Rebuildable and revalvable. Sold complete with bearings, travel indicator, and jam nut.
Collapsed Extended Damping Part No. Stroke Length Length Comp./Rebound
“AC” Series Aluminum Threaded-Body Shocks
minum impact extrusion and machined to the highest of
body shock eliminates the threaded tube from the coil- over kit. Shocks include bearing ends. Simply purchase
Part No.
Stroke
Collapsed Length
Extended Length
Damping Comp./Rebound
PROAC550B
5"
10.50"
15.50"
5/5
PROAC557B
5"
10.50"
15.50"
5/7
PROAC730B
7"
12.50"
19.50"
3/3
PROAC740B
7"
12.50"
19.50"
4/4
PROAC746B
7"
12.50"
19.50"
4/6
PROAC750B
7"
12.50"
19.50"
5/5
PROAC754B
7"
12.50"
19.50"
5/4
PROAC760B
7"
12.50"
19.50"
6/6
PROAC770B
7"
12.50"
19.50"
7/7
PROAC940B
9"
14.50"
23.50"
4/4
PROAC946B
9"
14.50"
23.50"
4/6
PROAC950B
9"
14.50"
23.50"
5/5
PROASB635B
6"
12.50"
19.50"
3/5
PROASB636B
6"
12.50"
19.50"
3/6
630 TRACK
CIRCLE 2021-22
