   Asphalt Late Model Headers (Cont.)
Crate Motor Crossover Headers
Fits crate engines in Bemco, Hamke, Howe, Lefthander, and Port City Chassis.
Tri-Y Crossover Headers SCH135VYCM
For small block Chevy crate motors with Vortec cylinder heads, crossover headers feature a 4-in-     increased torque. Headers include “stepped” 1-5/8"-1-3/4" primary tubes and 3" dia. collectors. Fits Hamke, Howe, Lefthander, and Port City chassis.
180° Crossover Headers

Howe, Port City, Lefthander offset chassis, and earlier straight-up models.
Vortec/Fast Burn Part No.
SCH135CM2**
“H” Style Part No.
—
Description
Chevy Headers
Primary Tube Dia.
1-5/8"
Collector Dia. x Length
3" x 8"
 SCH135CM
SCH135HCM*
Chevy Headers
1-5/8"
3" x 8"
 SCH135VCM-3
SCH135VHCM-3*
“Step” Headers
1-5/8"-1-3/4"
3" x 8"
* “H” Style headers fit Howe, Port City, and Stock Clip Cars (#7 tube extend- ed toward the rear and angled for clearance of foot box and chassis bars). ** 602 Crate
 Conventional
Crossover Headers
Small block Chevy headers extend away from the cylinder head and wrap behind the engine. Available for standard exhaust port engines only.
“H” Series Part No.
Description
Primary Tube Dia.
Collector Dia. x Length
Collector Dia. x Length
 SCHH180
Chevy Headers
1-3/4"
3-1/2" x 9"
SCHH180V
“Step” Headers
1-3/4"-1-7/8"
3-1/2" x 9"
  Standard Part No.
**602 Crate
Crate Motor Part No.
Description
Primary Tube Dia.
Collector Dia. x Length
Lower RH Door Exit
Headers are compatible with
a stock bellhousing and use 48" extensions. Applications available to       Chevy engines.
Primary Part No. Description Tube Dia.
 Lower RH Door Exit
SCH145
SCH145CM2**
Chevy Headers
1-5/8"
3" x 8"
SCH145V
—
“Step” Headers
1-5/8"-1-3/4"
3-1/2" x 8"
—
SCH145VCM-3
“Step” Headers
1-5/8"-1-3/4"
3" x 8"
SCH146
—
Chevy Headers
1-3/4"
3-1/2" x 8"
SCH146V
—
“Step” Headers
1-3/4"-1-7/8"
3-1/2" x 9"
  SCH179-1
Chevy Headers
1-5/8"
3" x 8"
SCH180-1
Chevy Headers
1-3/4"
3-1/2" x 9"
  Dirt Late Model Headers
Schoenfeld’s headers for small block Chevy-powered Dirt Late Models have long primary tubes for maximum torque and horse- power. Available in traditional and stepped tube design. Stepped tubes increase exhaust velocity, horsepower, and torque. Most headers are available in standard or spread exhaust port. Headers are also available for crate motor applications.
 Mastersbilt and Warrior Chassis
 Both headers go over the frame.
Standard Chevy Part No.
— SCH142-505LVG
Crate Motor
Part No. SCH141-505LVGCM-3 —
Primary Tube Dia. 1-5/8"-1-3/4" 1-3/4"-1-7/8"
Collector Dia. x Length 3" x 8" 3-1/2" x 9"
Chevy 18° Part No.
   Rocket Chassis/Bernheisel
Both headers go over the frame.
Standard Chevy Crate Motor Spread Port Part No. Part No. Part No.
Primary Tube Dia.
Collector Dia. x Length
 SCH141-525LV
—
—
—
1-5/8"-1-3/4"
3-1/2" x 8"
—
SCH141-525LVCM-3
—
—
1-5/8"-1-3/4"
3" x 8"
SCH142-525L
—
—
—
1-3/4"
3-1/2" x 8"
SCH142-525LV
—
SCH142-525LVSP
SCH142-525LV18
1-3/4"-1-7/8"
3-1/2" x 9"
American Made, Barry Wright, Bullitt, GRT, Larry Shaw, Raider, Rayburn, Stinger, and TNT Chassis

Standard Chevy Crate Motor Spread Port Chevy 18° Primary Collector Part No. Part No. Part No. Part No. Tube Dia. Dia. x Length
GM LS Crate Motor in Bullit, GRT, Shaw, Rayburn or Warrier Chassis
Part No. Description Primary Tube Dia. Collector Dia. x Length
