DRAG RACING
WEGO Wide-Band Air/Fuel Ratio Meters with Display and Data Logging
Air/fuel ratio meters provide a versa-
tile tuning aid for carbureted or fuel
injected engines, while incorporating
data logging capability. Ideal for on-
track or dyno testing, WEGO meters
are highly accurate with less than
+/-0.10 AFR error over 10.3-19.5 AFR range. Offered in single- or dual-channel display, each are sold complete with Bosch LSU 4.2 5-wire wide-band oxygen sensor(s) with extension cable(s), 18 x 1.5mm weld nut(s) for mounting sensor(s) to exhaust and CDROM software.
CD-1 Capacitive Discharge Ignition System
Capacitive discharge ignition offers
135 mil-
lijoules
of spark
energy out-
put with
the ability
to digitally
set launch, burnout, and maximum RPM limits with 100 RPM steps from 3,000-9,900 RPM. PC-programmable advance feature allows an RPM-based advance curve or a 3D timing map with boost proportional retard. Data logging capability is provided (unless noted) with a 16-Mbit DataFlash memory, while a single input and two general-purpose outputs allow high gear retard, burnout RPM limit, vehicle speed, and throttle position sensors.
SmartSpark LS Ignition Module DAY119001
Part No.
Description
DAY112002
Single-Channel WEGO III Wide-Band AFR Kit, with Display and Data Logging
DAY112005
Dual-Channel WEGO III Wide-Band AFR Kit, with Dual Display and Data Logging
DAY113001
Dual-Channel WEGO IV Wide-Band AFR Kit, with Dual Display and Data Logging
DAY114001
Single-Channel WEGO IV Wide-Band AFR Kit, with Display and Data Logging
Part No.
Description
DAY102003
CD-1 Ignition System Includes Ignition, Coil, USB Interface, and Wiring Harness
System Accessories
DAY102004
USB Interface, Required for Data Logging and Custom Programming
DAY115012
2-Bar MAP Sensor, Turbo/Supercharged Applications
Designed
for GM LS
engines (LS1/
LS2/LS6/LS7)
with 24- or
58-tooth crank
triggers that
have been
converted to
carburetion,
SmartSpark
LS Ignition Module is
preprogrammed with advance
tables suited to a wide range of high-performance applica- tions. USB interface and PC link allows programming custom advance curves based on RPM and manifold absolute pres- sure, if desired. Unit allows digitally setting launch, burnout, and maximum RPM limits in 100 RPM steps from 3,000- 9,900 RPM. Includes three input terminals that may be used for RPM limits and multiple retard functions. Required wiring harness sold separately.
WEGO Wide-Band Air/Fuel Ratio Interface DAY111004
WEGO Wide-Band Air/Fuel Ratio Inter-
face includes dual-channel 0-5V analog
AFR outputs that may be interfaced
with dyno instrumentation, vehicle
data acquisition systems, and engine
controls. Unit is highly accurate with
less than +/-0.10 AFR error over 10.3-
19.5 AFR range. Sold complete with
WEGO IIID unit, (2) Bosch LSU4.2 5-wire wide-band oxygen sensors, and (2) 18 x 1.5mm weld nuts.
Part No. Description
WEGO Accessories and Replacement Components
NC-2 Progressive Nitrous Controller and Vehicle Data Logger
DAY116002
The NC-2 can operate two nitrous
stages with progressive control
using pulse widths to modulate
the solenoid valves and control
the flow rate. Controller allows
matching nitrous system power
output to vehicle requirements,
while independently controlling
fuel and nitrous oxide flow for optimal air/fuel ratio. Built-in data logging features logs throttle position, RPM, and vehicle speed, and includes (2) 0-5 volt analog inputs. Sold complete with USB cable and Windows software.
DAY115001
Wide-Band Oxygen Sensor, Bosch LSU 4.2
DAY115003
18 x 1.5mm Weld Nut, Allows Installing Oxygen Sensor into Exhaust
DAY115007
18 x 1.5mm Stainless Steel Weld Nut, Allows Installing Oxygen Sensor into Exhaust
DAY115008
18 x 1.5mm Stainless Steel Hex Socket Plug, Allows Removing Oxygen Sensor
DAY115025
Grounded Wide-Band O2 Sensor, for WEGO Chassis Dyno System Kits Only NEW!
Part No.
Description
Wiring Harnesses
DAY119002
LS1/LS6 Remote Mount Wiring Harness
DAY119005
LS2/LS7 Remote Mount Wiring Harness
System Accessories
DAY102004
USB Interface, Includes 6' USB Cable and CDROM
DAY119007
Ignition Kit with Module and Interface
