Page 73 - 2022-23 Auto Performance Drag Racing

3/16" Nylon Brake Line
Caps and Plugs
ALL50825
DRAG RACING
Fittings & Hoses
Part No.
Description
ALL48026
A must for keeping debris out of lines
and hoses. Ideal for keeping internal
components of dry sump pumps, fuel
pumps, pressure regulators, etc. clean during
storage. Caps and plugs fit 37° flared fittings and straight threaded ports. Available in plastic and aluminum.
ALL48026
10'
ALL48027
50'
ALL48028
100'
3/16" Nylon Brake Line Compression Fittings
ALL48032 ALL48033 ALL48034 ALL48035
Part No. Description
3/16" Nylon Brake Line Push Lock Fittings
Cap Plug
AN Size
Thread Size
ALL50815
No. Per Pkg.
Plastic Caps and Plugs
ALL50801
ALL50811
-3
3/8"-24
20
ALL50802
ALL50812
-4
7/16"-20
20
ALL50803
ALL50813
-6
9/16"-18
20
ALL50804
ALL50814
-8
3/4"-16
20
ALL50805
ALL50815
-10
7/8"-14
10
ALL50806
ALL50816
-12
1-1/16"-12
10
ALL50807
ALL50817
-16
1-5/16"-12
10
ALL50808
ALL50818
-20
1-5/8"-12
5
Aluminum Caps and Plugs
ALL50821
ALL50831
-3
3/8"-24
20
ALL50822
ALL50832
-4
7/16"-20
20
ALL50823
ALL50833
-6
9/16"-18
20
ALL50824
ALL50834
-8
3/4"-16
20
ALL50825
ALL50835
-10
7/8"-14
10
ALL50826
ALL50836
-12
1-1/16"-12
10
ALL50827
ALL50837
-16
1-5/16"-12
10
ALL48036
ALL48032
1/8"-27NPT Male to 3/16" Straight
ALL48033
1/8"-27NPT Male to 3/16" 90°
ALL48034
3/16" Union
ALL48035
3/16" Tee, All Compression
ALL48036
3/16" Captured End Caps, 10-Pack
ALL48020
Part No.
ALL48021
ALL48022
ALL48023
Cap and Plug Kits
Kits include five of each size, -3 to -16.
ALL50800
Description
ALL48020
1/8"-27NPT Male to 3/16"
ALL48021
1/8"-27NPT Female to 3/16"
ALL48022
3/16" Tee, All Push Lock
ALL48023
3/16" Tee, Two Pushlock And One 1/8"-27NPT Male
ALL50800
Plastic Cap Kit
ALL50810
Plastic Plug Kit
ALL50820
Aluminum Cap Kit
ALL50830
Aluminum Plug Kit
Aluminum Fuel Line
Allstar aluminum fuel line is seamless and available in three diameters. 25' coil.
Part No. Description
Grommet Set ALL18360
ALL40185
Grommets are perfect for protecting wir- ing and hoses that pass through panels
up to 1/16" (.062") thick. Kit includes 36 grommets (6 of each size: 1/4", 5/16", 3/8", 1/2", 5/8", and 11/16"). Grommets are also available in size-specific 10-packs.
Part No.
Fuel Cell Hose
Description
ALL40180
3/8" Dia.
ALL40185
1/2" Dia.
ALL40186
5/8" Dia.
Part No.
Vacuum Line
Grommet Hole I.D.
Panel Hole I.D.
ALL40340
ALL18362
3/16"
5/16"
ALL18363
1/4"
3/8"
ALL18364
5/16"
7/16"
ALL18365
3/8"
1/2"
ALL18366
1/2"
5/8"
ALL18367
5/8"
7/8"
ALL18368
11/16"
1"
Clear vent and filler hose is ideal for Circle Track cars. Sold in pre-cut lengths
of 5', 10' and 20'.
Description
5' 10'
ALL40160-5
20'
1" I.D. Vent Hose
ALL40160-5
ALL40160-10
ALL40160-20
1-1/4" I.D. Vent Hose
ALL40161-5
ALL40161-10
ALL40161-20
1-1/2" I.D. Vent Hose
ALL40162-5
ALL40162-10
ALL40162-20
2-1/4" I.D. Filler Hose
ALL40168-5
ALL40168-10
ALL40168-20
2-1/2" I.D. Filler Hose
ALL40170-5
ALL40170-10
ALL40170-20
Premium vacuum line resists kinking
and is pliable for easy routing. Often
used when connecting sensors, vacuum advance units, windshield washers or replacing existing cracked, leaking vacuum lines. Size indicated is I.D. of hose.
Part No. Description
ALL40340
5/32", 5' Long
ALL40341
5/32", 50' Long
ALL40342
7/32", 5' Long
ALL40343
7/32", 50' Long
71
2022-23
