P. 456
TKO 5-Speed Manual Transmissions
-
Part No.
TRETCET4616 TRETCET4617 TRETCET4618 TRETCET5008 TRETCET5009
Model
GM TKO-500 Ford TKO-600 GM TKO-600 Ford TKO-600 GM TKO-600
Torque Capacity
500 Lb-Ft 600 Lb-Ft 600 Lb-Ft 600 Lb-Ft. 600 Lb-Ft
Input Spline
26 26 26 26 26
Output Spline
31 31 31 31 31
1st
3.27 2.87 2.87 2.87 2.87
2nd
1.97 1.89 1.89 1.89 1.89
2nd
3rd 4th
1.34 1.00 1.28 1.00 1.28 1.00 1.28 1.00 1.28 1.00
3rd 4th
5th
.68 .82 .82 .64 .64
5th 6th
T-56 Magnum 6-Speed Manual Transmission
Part No.
TRETUET11009
TRETUET11012 TRETUET11010
Model
GM LS
GM LS Ford Mod
Clutch
Hydraulic
Hydraulic Cable/Hydraulic
Speedo Drive
Mech & Electric
Mech & Electric Mech & Electric
Input Spline
26
26 26
Output Spline
31
31 31
1st
2.66 1.78
2.97 2.10 2.66 1.78
1.30 1.00 0.80 0.63
1.46 1.00 0.74 0.50 1.30 1.00 0.80 0.63
T-5 5-Speed Manual Transmission
TRE1352-000-251
Note: Tremec recommends using Mobil 1 synthetic ATF.
Ford 5.0L 300 ft./lbs. Hyd. Elec. 10/28 2.95 1.94 1.34 1.00 .63 2.76
Application
Engine
Torque Capacity
Clutch Type
Speedo Type
Input/Output Spline
Gear Ratio
1st
2nd
3rd
4th
5th
Rev.
TKO Transmission Accessories Part No.
Description
TRE2606249 TRE2-3-6041X TRE30-360-1X
Reverse Light Switch Fits 5 Speeds
Transmission Slip Yoke, TKO, 31-Spline
Mech. Speedo Plug Kit, Seals Mech. Speedo Opening When Elec. Speedo Is Used.
Small Block Ford Cast Aluminum Valve Covers
TRFTFS-51411801
Differential Covers
Part No.
TRFTFS-8510300
TRFTFS-8510400
TRFTFS-8510500
Description
GM 8.2"/8.5"
GM 7.5"
Ford 8.8"
TRFTFS-8510300
454
