Page 1255 - 2025 Parts & Accessories Catalogue

ADAPTERS/TRAILER ACCESSORIES
TRAILER ADAPTER
Adapter allows a tow vehicle with a 4, 6 or 7 pole socket to tow a trailer with a different configuration plug. Quality molded plastic connector stores in glove box when not in use.
7 Pole RV Style Blade to 5 pole flat - 18" extension harness Mfr. No. TC50000 ORDER NO. 051-50000
TRAILER ACCESSORIES
CARSIDE CONNECTOR
48", 16 GA 4/Pole Ready-Wired #B240010 Mfr. No. WH10040 ORDER NO. 051-10040
CARSIDE CONNECTOR
48", 16 GA 5/Pole Ready-Wired #M242010 Mfr. No. WH10230 ORDER NO. 051-10230
For more information see: catalog.sierraparts.com
7-WAY TRAILER CONNECTOR ADAPTER • Simple plug-and-play
design eliminates the need for cutting or splicing
TRAILER SIDE CONNECTOR
24", 16 GA 5/Pole Ready-Wired #M243120 Mfr. No. WH10240 ORDER NO. 051-10240
TRAILER SIDE CONNECTOR
514-57241
24", 16 GA, 4/Pole Ready Wired #M241120 Mfr. No. WH10220 ORDER NO. 051-10220
514-57251
Center Pin Function
-
-
POLARIZED 2-WIRE FLAT CONNECTOR 12", 16 GA, 2 Plugs Ready Wired #E301120 Mfr. No. WH10300 ORDER NO. 051-10300
Mfr. No. From Vehicle
57241 7-Way RV Blade
57251 7-Way RV Blade
ORDER NO.
514-57241
514-57251
To Trailer
4-Way Flat
5-Way Flat
514-58031
Description
Plug w/ bonded wire
4-WAY FLAT TRAILER CONNECTOR PLUG W/ 12" WIRES (TRAILER SIDE) • Splices into trailer wiring to provide a
connection to the vehicle socket • 4-Way flat output connects tail lights,
brake lights, and turn lights • Constructed with bonded 16-gauge wires
and durable molded rubber • Features 12" of colour-coded wire
for easier installation • Designed for use on vehicles and trailers
4-WAY FLAT TRAILER CONNECTOR SOCKET W/ 60" WIRES (VEHICLE SIDE) • Splices into trailer wiring to provide a
connection to the trailer plug • 4-Way flat output connects tail lights,
brake lights, and turn lights • Constructed with bonded 16-gauge wires
and durable molded rubber • Features 60" of colour-coded wire
for easier installation • Designed for use on vehicles and trailers
514-58041
with two-wire systems ORDER NO. Mfr. No.
514-58031 58031
with two-wire systems
Wire Length
12"
ORDER NO.
514-58041
Mfr. No.
58041
Wire Length
60"
Description
Socket w/ bonded wire
Includes snap locks and hardware.
Includes snap locks and hardware.
For more information see: www.curtmfg.com
1223
