ELECTRIC WINCHES
SA SERIES ELECTRIC WINCHES
• Features Power-in, Power-out, controlled Freewheeling clutch and automatic brake. • Available in 120 volt AC and 12 volt DC models. • SA model equipped with flexible high strength 7 x 19 galvanized aircraft cable.
SA9000 and SA12000 also accept 2" wide strap. • Emergency crank handle is standard equipment.
AC MODELS
• 120 volt AC operation complete with 10 foot, 3 wire ground power cord and built-in 3 position rocker switch.
• Available with CSA NRTL/C approval, signifying the winch has been evaluated to applicable ANSI/UL and CSA standards for use in the U.S. & Canada. NRTL (Nationally Recognized Testing Laboratory) is designation granted by OSHA to laboratories which have been recognized to perform certification to U.S. standards.
DC MODELS
• High-torque 12 volt DC motor has circuit-breaker overload protection. • StrongArm® DC electric winches have a dynamic motor break as well as a mechanical
friction brake to securely hold the load. • DC models include wiring harness, 25 foot positive battery wire, and 8 foot ground wire.
Electric Winches
069-09000
069-12001
ORDER NO.
069-09000 069-09001 069-12000 069-12001
VOLTS
12V DC 120V AC 12V DC 120V AC
RATED LOAD CAPACITY GEAR
RATIO
CABLE SIZE LENGTH
7/32" x 25' 7/32" x 25' 7/32" x 50' 7/32" x 50'
PULLEY BLOCK & HOOK
• •
MODEL NO.
SA9000 SA9000AC SA12000 SA12000AC
3000 lbs. 2700 lbs. 4500 lbs.(1) 4000 lbs.(1)
570:1 570:1 570:1 570:1
(1) Double Line Operation
ELECTRIC WINCH CONTROLS
The electric switch and clutch controls are both located on the same side for easy operation. The electric switch powers the load in and out - when released, it automatically returns to the “off” position. The clutch control provides for smooth load control from a locked to a free- wheeling position. It automatically returns to a locked position when released.
The clutch can be used for a controlled load release without electric power, if desired. The clutch can also be locked in the free-wheeling position for easy cable removal.
All D-L StrongArm® electric winches are built for multi-purpose hauling and pulling operations. They are not to be used as hoists for lifting, supporting, or transporting people; or for handling loads over areas where people could be present.
GUIDE TO ROLLING LOAD CAPACITY (3) Maximum weight in rolling load pounds. PERCENT INCLINE
Approximate Amperage Drain (Full Load) AC Models 6 Amps DC Models 70 Amps
For intermittent use only. Ratings are based on 10' lift. For longer lifts at full capacity occasional motor cooling periods should be allowed.
LENGTH OF CABLE ON REEL (FT.)
APPROXIMATE LOAD SPEED (FT./MIN.)
LOAD CAPACITY
3,000 lbs.
2,700 lbs.
Double Line 4,500 lbs.
Double Line 4,000 lbs.
NO LOAD
LOAD CAPACITY
MODEL NO.
SA9000
SA9000AC
SA12000
SA12000AC
5% (3)
20,000
18,000
30,000
26,600
10% (6)
15,000
13,500
22,500
20,000
20% (11)
10,200
9,100
15,300
13,600
30% (17)
7,800
7,000
11,700
10,400
50% (26)
5,500
5,000
8,300
7,400
70% (35)
4,500
4,100
6,800
6,100
Full Reel
11
18
5
9
Empty Reel
Full Reel
Empty Reel
2.5
3.5
1.5
5 4
6 7
2.5 2
3 4
2
All capacities shown are with 15' of cable on the reel and a 10% rolling friction factor. For a full reel of cable adjust capacities according to graph above.
Note 5% incline is one half foot rise in ten feet.
For more information see: wwww.dutton-lainson.com
12 51
DEAD WEIGHT CAPACITY (LBS.)
