VHF /ANNTENNA ACCESSORIES
276-00258-1
276-00259-1
VHF ACCESSORIES
Shakespeare Revolutionizes The PL-259/PL-258 Centerpin®
The perfect solution to the troublesome task of installing a PL-259 connector or splicing RG-58 A/U or RG-8/X coax. Shakespeare’s revolutionary new Centerpin® connectors are solderless, fret-less, and botchless. They go on without a hitch, without soldering skills. No measuring, no critical stripping of coax insulation, no fussing with the coax’s braid, and no “tinning”. New connectors are gold-plated brass to better withstand the elments and to minimize traditional connector-borne signal loss.
Centerpin® PL-258-CP-G: The easy way to splice coax! The new Centerpin® PL-258-CP-G connector puts Centerpin® convenience to work on the double- trouble task of splicing RG-58 A/U and RG-8X. ORDER NO. 276-00258-1
Centerpin® PL-259-CP-G: For RG-58 A/U and RG-8X coax. Installing a PL-259-G connector hasn’t been simple. Now it is. ORDER NO. 276-00259-1
Mfr. No. PL 259-CP-G
Mfr. No. PL 258-CP-G
SHAKESPEARE STYLE ART-3 TESTER
Specifications:
No need to call for a radio check when you have this compact, easy to use, • Frequency Range: 155-158 MHz
• Signal Generator: 3 KHz Deviation • Tone: 1000 Hz • RF Level: -15 dBM ( approx.) • Die-cast aluminum construction
• Two PL-259 connectors on each end, already installed
• RF Power Scale: 0 to 30 watts • Impedance: 50 ohms • Accuracy: ±10%
unit on-board. Unlike other meters in its class, the ART-3 tests receiver function as well as output power and VSWR (antenna efficiency). It is powered by an internal battery or can be connected to ships 12 VDC with the supplied power cable. Battery level can be checked at the flip of a • Connectors: SO-239
switch. No serious boater should be without an ART-3 Mfr. No ART-3 ORDER NO. 276-00030
For more information see: www.shakespeare-marine.com
MALE UHF CONNECTOR & REDUCERS FOR 8U CABLE - Nickel Plated Brass
ORDER NO.
423-29900
423-29902
423-29906
Mfr. No.
329900-1
329902-1
329906-1
Description
Male UHF Connector; PL-259 - For U/C Cable, Adapter Type
Combination of 329900-1 & 329906 - For RG-59/U Cable
Reducer - UG176U for RG-59/U Cable - Use with 329900
UHF RIGHT ANGLE CABLE CONNECTOR - Nickel Plated Brass
ORDER NO. Mfr. No. A B C
423-29955 329955-1 1-1/8" 1-5/16" 11/16"
90˚ elbow turns connecting wire at the back of set allowing radio to sit closer to a back wall or bulkhead.
UHF CONNECTOR
Twist on UHF Male Plug (PL259)
ORDER NO. Mfr. No. Wire Size
422-02175 ea 202175 RG58
For more information see: www.ancorproducts.com
For more information see: www.sea-dog.com
WATERTIGHT DECK CONNECTION Antenna Feed-thru
Rated for 15 Amps at 12, 24 and 32 Volts. Polarized double contact connector. Accepts up to #14 gauge stranded wire.Chrome plated zinc and has a flange gasket with integral waterproof cap for base when plug is removed.
Diameter: 1-5/8" / Height: 1-3/16" / Screw Size: 6 ORDER NO. 621-11900 Mfr. No. 1190DP0CHR
For more information see: www.perko.com
