STEERING HELMS/BEZELS
4.2 NON NFB ROTARY STEERING COMPONENTS
4.2 Turn Helm
KIT COMPONENTS
ORDER NO.
073-49510
070-27484
078-62xx0
Mfr. No.
SH4951P
SB27484P
SSC62XX
Description
Single Cable - 4.2 Turn
90˚ Bezel Kit
Steering Cable
Description
4.2 NON NFB Single Cable - Tilt Helm*
4.2 NON NFB Dual Cable - Tilt Helm*
4.2 NON NFB Dual Cable - Helm
Sport Tilt Mechanism
Sport Plus Tilt Mechanism
20˚ Bezel Kit
Cable Guard
XX = Length in feet.
OPTIONS
ORDER NO.
073-49710
073-94952
073-49520
073-91800
073-91900
070-27483
069-39329
Mfr. No.
SH4971P
SH94952P
SH4952P
SH91800P
SH91900P
SB27483P
SA39329P
SERVICE ITEMS
ORDER NO.
069-27454
069-38603
Mfr. No.
SH4951P
SA38603P
Description
Steering Wheel Hardware Kit
Spent Travel Tube
070-27150
90˚ Bezel
073-49200
Dual Cable
070-27150
90˚ Bezel-Safe T II
073-50940-1
* Requires tilt mechanism to complete Tilt Steering system installation.
HELM/BEZEL VISUAL IDENTIFICATION GUIDE
This is an overview of Dometic ROTARY steering helms likely to be encountered.
NFBTM 4.2
• Two bolts secure QC cable to helm. • One bolt holds spent travel tube. • Cast finish helms have No FeedBackTM feature. Kits: 084-147XX (4.2 Single Cable),
NFBTM SAFE-T II & HPS ROTARYTM • Collet & hitch pin secure QC cable to helm. • One bolt holds spent travel tube. • Safe-T II cast finish helm has No FeedBackTM
feature; HPS gold-finish helm does not.
Kit: 084-132XX (Safe-T II Single Cable); HPS Rotary is sold as components only.
SAFE-T® QC
• Collet & hitch pin secure QC cable to helm. • Conical plastic nut holds spent travel tube.
070-27483
20˚ Bezel
073-49100
Single Cable
070-27483
20˚ Bezel-Safe T II & HPS
073-51500
Safe T II- cast finish
070-27484
90˚ Bezel-HPS
070-27484
90˚ Bezel
070-27483
20˚ Bezel
Kit: 082-137XX (Safe-T QC Single Cable) NOTE: The old style helm has a threaded spent travel tube.
The 073-5094-1P is a quick connect spent travel tube. Both use the same cable.
JBS HELMS
Just for Jets! JBS by Dometic means Jet Boat Steering. Designed exclusively for jet boats, JBS features a choice of two steering arcs, a real steering cable (not a control cable) plus an assortment of mounting options for virtually any boat. Nobody knows steering like Dometic!
073-50870
JBS HELM (135° Turning Arc)
073-50880
JBS HELM (270° Turning Arc)
For more information see: www.dometic.com
