VENTS - CLAMSHELL/LOUVERED
PLASTIC LOUVERED VENTS
• ABS plastic, will not rust, discolour or streak. • No dangerous sharp edges to scratch or cut hands or feet. • Designed for gunwale mounting to assure high-vent mounting
so that the boat will meet and pass the tip test. • 3-7/16" wide x 17-7/8" long x 3/4" high (1" neck). • Installation hole size: 2-1/4" x 16-1/8". • Pre-drilled with six mounting holes for size #8 screws. ORDER NO. 101-14950 - Off-White Mfr. No. 1495-1
COLLECTOR BOXES
For use with Venturi, Flush Louvered or Trimline Vents. Corrosion-resistant plastic.
ORDER NO. Mfr. No. Description Depth 101-13411 1341-1 For two 3" I.D. hoses 3-7/8" For use with 1494 - 101-14941, 1423, 1424, 1425, 1426, 1496A
101-13421 1342-1 For one 4" I.D. hose 5" For use with 1494 - 101-14941, 1423, 1424, 1496A
COLLECTOR BOXES
Installation Hole 2-1/16" x 15-9/16"
2-1/8" x 15-5/8"
For use with plastic louvered vent, with two 3" I.D. wire-supported ventilation hoses. Box fastens to vent with screws or pop rivets, then vent fastens to the deck. Corrosion-resistant plastic.
ORDER NO. Mfr. No. Description Depth Installation Hole
101-13451 1345-1 For two 3" I.D. hoses 4" 2-7/16" x 16-1/4" For use with 1495 - 101-14950, 101-14951
LOUVERED VENT
Measures 14" (356mm) long, 5-3/4" (146 mm) high and 1" (25 mm) deep with 1/2" (13 mm) flush height. Cut-out is 12-1/4" (311 mm) by 3-3/4" (95 mm). ORDER NO. 107-07210 - White
For more information see: www.detmarcorp.com
SLOTTED VENTILATOR
Stamped 316 Stainless
ORDER NO. Mfr. No. LOUVERS A B C D E F Vent Area
423-31290 331290-3 5 3-5/8" 12" 4-1/2" 12-7/8" 13/16" 1" 11.65 in2
COWL VENT WITH BASE - Stamped 304 Stainless/Plastic
Fastener
# 6 RH
ORDER NO. Mfr. No. A B C
423-31320 331320-1 5-7/8" 4-7/16" 3-5/16"
CLAM SHELL VENT - Stamped 304 Stainless
D E F Fastener
2-1/2" 3-9/16" 2-3/4" #8 FH
Vent Area Fastener
ORDER NO. Mfr. No.
423-31335 331335-1
423-31340 331340-1
423-31350 331350-1
LOUVERED VENT -
ORDER NO. Mfr. No.
423-31400 331400-1
A
5"
7"
7-1/2"
B
4-1/2"
5-3/4"
6-3/4"
C
2"
2-1/4"
2-7/8"
4.51 in2
7.51 in2
12.02 in2
Fastener
#6 RH
# 6 RH
# 6 RH
# 6 RH
Stamped 304 Stainless
A B Vented Area
2 9-1/8" 4-5/8" 3.24 in
