INSTALLATION KIT/FLOAT SWITCHES
TSUNAMI Mk2 BILGE PUMP INSTALLATION KITS
Complete kit to install manual bilge pump with 3⁄4” ID hose outlet.
Includes:
• (1) 2-way On/Off switch with bezel plate • (1) 3⁄4" ID x 5’ corrugated hose • (1) Thru-hull fitting for 3⁄4” ID hose • (2) Snap-It hose clamps
• (1) Two-conductor 16 gauge wire, 20' long • (1) In-line fuse holder with 2-amp fuse Caution: Bilge pump switches are not external ignition protected.
AUTOMATIC FLOAT SWITCHES
104-41160
ORDER NO.
104-41160
105-56140
Mfr. No.
4116-5
5614-7
Description
Complete Kit without Pump
Complete Kit
with Tsunami Mk2 T-500 Bilge Pump
(105-56060)
1
The Automatic Float Switch converts any bilge pump that draws 12 amps (at 12 VDC) or less to fully automatic operation. It features a compact, low-profile design that mounts on any surface from horizontal up to a 24° angle. No large voltage drop which reduces bilge pump output. Incorporates a reliable and affordable mechanical switch that actuates pump motor at 2" water level. Wire leads do not flex or hinge with the float. Integral cover dampens bilge sloshing to reduce pump cycling, and prevents debris interference. Sealed switch mechanism resists moisture, fume ignition and electrical shock. Contains no mercury, a "Persistent Toxic Substance" listed as a health hazard. CE rated. Float switch installs independently or directly onto the rear slots of the V-Series pump bracket. Features a convenient test knob to test pump operation.
04-42020
104-42010
Mfr. No.
4801-7
ORDER NO.
104-42010
104-42020
Mfr. No.
4201BL
4202-7
Description
Float switch with cover 12 and 24 Volt
Float switch 12 and 24 Volt
ELECTRIC BILGE SWITCH - S3 SERIES - 12V - DIGITAL
• Fully Sealed Electronics - No moving parts • Solid State Electronic Sensing Technology to detect bilge water levels & trigger pump activation • Won’t be exposed to continuous cycling • Can be mounted on the floor of the bilge directly to a stringer alongside the basket of the pump • Directly compatible with competitive products
ORDER NO.
104-48010
For more information see: www.attwoodmarine.com
Features:
ULTIMA SWITCH␣
Mercury Free design with no moving parts. Completely sealed Solid State Design. Automatic bilge pump switch 12/24V DC 20 amp draw. Detects fluid using the patented MirusTM "field effect" technology.
ORDER NO. 671-36303 Mfr. No. 36303
AUTOMATIC FLOAT SWITCH
FOR A BETTER AND SAFER LIFE AFLOAT! For full automatic bilge pumping operation, connect the automatic switch to your bilge pump. The AS888 has a time proven micro switch without mercury. When water exceeds the acceptable level, the pump is turned on by a rolling steel ball, which changes the pressure on the micro switch. • Can be mounted to all Johnson Pump submersible bilge pumps
through the clip-on “T-slot” & can be used with 6, 12, 24,
• 3-year warranty • Turns pump on at 2" fluid level • Turns pump off at 3/4" fluid level • Not effected by oil, fuel or debris • Reverse wire protection • 12/24V DC operation • Handles all pumps up to 20 amp draw • Meets ISO 8846, ABYC, NMMA and USCG • Made in USA
ELECTRONIC FLOAT SWITCH
The Electronic Float Switch is built on the same concept as the switch on Cartridge Duo. As a separate accessory it is possible to attach the switch to all Johnson bilge pumps. • 12 Volt
• Can be mounted to all Johnson Pump submersible bilge pumps
• Can be used with 6, 12, 24, or 32 Volt systems
• Non clogging switch • No false starts • Saltwater tough • Easy to clean Mercury Free • Pre-wired for manual override
• Universal mounting plate • Max Amp: 15 A ORDER NO. 847-36152 Mfr. No. 36152
or 32 Volt systems • Non-clogging switch • No false starts • Saltwater tough • Easy to clean • Pre-wired for manual override • Universal mounting plate • Max Amp: 15 A ORDER NO. 847-26014 Mfr. No. 26014
Mercury Free
For more information see: www.spxflow.com/johnson-pump-marine
