Page 880 - 2025 Parts & Accessories Catalogue

SHOWER SUMP PUMP/SHOWER DRAIN
MULTIPLE PORT SHOWER SUMP WITH ULTIMA SWITCH
Mercury Free with no moving parts
This compact shower sump pump system is designed to meet the higher demands from today’s boating industry where more equipment is used. This also includes the fresh water systems onboard and involves shower, dish-washing machines, galley sinks, etc. The shower sump turns on/off automatically using the Ultima switch technology and has multiple inlet ports for handling waste water from more than one tapping point. Equipped with a check valve on the outlet which stops water flowing back into the tank. The tank has a tight-fitting lid to minimize splashing & odours. To further aid in cleaning, the system includes an easily removable mesh filter.
Mercury free
Mfr. No.57151
ORDER NO. 847-57151
For more information see: spxflow.com/johnson-pump-marine
SHOWER DRAIN SUMP SYSTEM
12 Volt
• Compact, full-capacity shower drain system • Activated by a float switch, it turns on as the tank
fills and shuts off when it's empty • Three inlet ports that offer varying combinations for the inlet hose,
as well as a quick-release tank lid and an easy-clean internal strainer
For more information see: www.xylem.com
• Capacity: • Capacity: • Voltage: • Amperage: • Fuse Size: • Intake Hose:
• Discharge Hose: • Dimensions: • Weight:
972 GPH Straight (13.6 V): 61 l/min 1.0m head (13.6 V): 844 GPH / 53 L/min 12 V 3.4 A / 2 A 5 A / 3 A 1 x 3/4”, 1 x 3/4” or 1 x 1”, 1 x 1-1/8” or 1 x 1-1/2” 3/4” 11.5” L X 8.26” W X 5.7” H 2.3 lbs.
ORDER NO.
Mfr. No.
Nominal GPH / LPH
Amps @
Amps @
Discharge
Ports
Check Valve
Discharge Hose Diameter
Size LxWxH
272-00098B
98B
800 / 3028
2.9 (12V)
3.5 (13.6V)
3/4"
Yes
Yes
3/4" (19mm)
9" x 9.5" x 5"
272-00099B
99B
1100 / 4164
3.7 (12V)
4.5 (13.6V)
3/4"
Yes
Yes
1-1/8" (29mm)
9" x 9.5" x 5"
