Page 39 - Catalogue 2020 v.2.10
P. 39
WIRELESS DATA MODEM
SERIAL - WIRELESS DATA MODEM
DATA & VOICE
RE620/443I RE620/243I RE620/743I
OPTION - 40W/50W
DATA ONLY
RE643/443I RE643/243I RE643/743I
OPTION - 40W/50W
ST682
IK651
PS010
DKK €
66 - 88 MHz 135 - 174 MHz 350 - 470 MHz
DKK €
66 - 88 MHz 135 - 174 MHz 350 - 470 MHz
8.060,00 1.084,00
Simplex/Semi-duplex transceiver TP6000i, data 4800 / 9600 GMSK (25 kHz) and voice with controller / RS232 (RXD & TXD only), interface and audio power amplifier, 13.2 VDC. With transparent data or protocol
OPTION: VHF 2m we have 50 Watt modules and for UHF we have 40Watt modules
7.316,00 984,00
Simplex/Semi-duplex transceiver TP6000i, data 4800 / 9600 GMSK (25 kHz) with controller / RS232 (RXD & TXD only), interface, 13.2 VDC. With transparent data or protocol
OPTION: VHF 2m we have 50 Watt modules and for UHF we have 40Watt modules
605,00 82,00
Installation cable for data & voice radios. Connects radio to PC or data equipment and to speaker microphone. Female hirose microphone connector (microphone end, can be screw attached to surface), D-25 female (radio end), D-9 (PC or data terminal end)
132,00 18,00
Power cable for GMSK data radio
Red and black 2.5mm 2 lines, covered in black outer insulation. 5m
853,00 115,00
Power supply kit 100 – 240 V / 12 V 8.5 A for TP6000i GMSK EU Power cable (ST-1109) included
DKK €
DKK €
DKK €
TP Radio, Agenavej 37, 2670 Greve, Denmark, Phone +45 43906048, www.tpradio.dk, Mail: sales@tpradio.dk Price excluding VAT / Typographical errors are not binding / 2020
39
