P. 253
Workshop equipment
Workbench vices
Tool holder
Application: Two interchangeable clamping jaws
For clamping tools with a round shank No. 51003:
With plastic grip
Execution: Steel chuck and union nut No. 51002
No. 51002:
With nickel-plated brass grip
Min./max. clamping width 0-3.2 mm 2-3 mm 3-4.5 mm 4-6 mm
Length (mm) 100 135 150 165
Shaft Ø (mm) 9 15 17 18 No. 51003
51002... 51003... 51003... 51003...
ID no. ID no. ID no. ID no.
110 O. R. 200 O. R. 205 O. R. 210 O. R.
Unit price, €
Prod. group 510
Tool holder
With ratchet in all-steel construction
Application: Movable T-handle
For mounting tools with square shank. Ratchet function, reversible
Execution: Advantage:
Dual-jaw chuck with hardened jaws Clockwise/anti-clockwise rotation and rigid
Chrome-plated and polished surface application
Min./max. clamping width of
square 2-5 mm 2-5 mm 4.6-8 mm 4.6-8 mm 9-12.5 mm
Suitable for min./max. screw
tap M3-M8 M3-M8 M5-M12 M5-M12 M13-M20
Length (mm) 85 250 110 300 117
510
530
540
500
520
Ident. No.
51005... Unit price, € O. R. O. R. O. R. O. R. O. R.
Prod. group 510
Vice jaws
Made of steel, forged
Application: With slanting jaw
For clamping and holding smaller workpieces. With captive bracing spring
Execution:
General tools
Made of steel, forged
Jaws width (mm) 28
Length (mm) 125
500
Ident. No.
51013... Unit price, € O. R.
Prod. group 510
Filing vice
Made of steel, forged
Application: With trapezoidal spindle and wing nut
For clamping and holding smaller workpieces. With captive bracing spring
Execution:
Made of steel, forged
Jaws width (mm) 36 40 42 48 52 55
Length (mm) 100 120 130 145 160 180
550
540
560
510
520
530
Ident. No.
51016... Unit price, € O. R. O. R. O. R. O. R. O. R. O. R.
Prod. group 510
