Digital Logic Circuits 8
EQUIVALEN
Many different logic diagrams ar
F = ABC + ABC’ + A’C .......
= AB(C + C’) + A’C [13]
= AB • 1 + A’C [7]
= AB + A’C [4]
A
(1) B
C
(2) A
B
C
(3) A
B
C
