“Durability is paramount.

We chose everything for Airtight envelopes. Superior glazing. Extra protection. Tyvek DrainWrap from DuPont
Nudura-insulated concrete
a remote location. In fact, forms (ICF) stem walls work Triple-pane tilt-and-turn combines air and water resistance and vapor
permeability with a vertically grooved surface
in tandem with walls and
I can’t pull out one product roofs made from Big Sky’s 4700-Series ThermoPlus designed to provide enhanced drainage and protect
windows from EuroLine
against wind-driven rain.
R-Control structural insulated
and say it is the weak link. panels (SIPs), donated by the Windows Inc. complete
the envelopes.
Everything selected is best Structural Insulated Panel
Association (SIPA), to create
of class—every single thing.” airtight, thermal-bridge free
building shells.
———RON JONES, OWNER,

DESIGNER, BUILDER

IMPENETRABLE ROOFING AND SIDING
Jones and Gutterman shared a concern for fire resistance and durability
when they were choosing the siding and roof. “Standing seam metal roof-
ing was a no-brainer,” says Jones. While they selected the Fabral roofing
for its exceptional resilience, they also designed the project so that no
penetrations would go through the product.
“There are no hollow soffits on the houses because sparks can come in
through soffits,” Jones explains. “We also vented everything out through
the sides of the houses through the gables. The [energy recovery ventila-
tion], plumbing, exhaust fans and vents all go out through the walls.”
Jones did this partly because of the heavy snow loads the houses will
bear. With no penetrations on the 9:12-pitch roofs, the snow slides off the
roof, and what snow remains will not infiltrate the house. The impenetra-
ble roof also provides protection against embers should a forest fire occur.
For a similar reason, Jones opted for James Hardie fiber cement sid-
ing and trim. The vertical board-and-batten product is fire resistant and
durable, while its solid color qualities and dimensional stability elimi-
nates cracking or peeling. James Hardie offers the siding prefinished with
ColorPlus technology, which gave Jones 25 colors to choose from and
the promise of low maintenance even at high elevation with its severe
weather and with strong ultraviolet rays.
The masonry veneer wainscoting by Creative Mines is a sustainable
product that uses natural pumice pozzolan in its 70 percent post-industrial
recycled content, replacing smokestack-produced fly ash. The application Durable access. Clopay’s eco-friendly garage doors
of this stone will be part of the next few months’ work, along with the offer structural integrity and energy efficiency, while
expansive fire-resistant, low-maintenance Trex hardscaping in the outdoor the garage boasts an Uponor radiant heating system
living areas, once the buildings have been completely finished. and houses components of mechanical and energy
Jones is particularly excited about these important finishing touches, systems through all seasons.
as they will bring these super-insulated structures to life, emphasizing
that beauty, sanctuary, livability and comfort are the hallmarks of home.
Follow along as we highlight these portions of the exterior build in upcom- High-Performance
ing articles. In the meantime, check out the VISION House at Mariposa
Meadows story online for more details about the project tenets, building
Products Meet
science and innovative products. GB

Resources:
Green Builder Media: “How to Run Electric Through SIPS”
■ Extreme Climate
Green Builder Media: “Mariposa Meadows: Live Life Free”
■
SIPA: “Building With SIPs: Need to Know”
■
SIPA: “Designing With SIPs: Design Considerations”
■
