Coaxial Cable Stripping Tools

Stripping & Chamfering

TXFF & TXFF-Q Series

MegaDrop Cable Stripper
• Color-coded tool exposes the center conductor & removes the jacket on Times Fiber Communications
MegaDrop TX-10-15 Low Loss Drop Cable and F50 CommScope cable
®
• The first cut prepares the cable to the proper center conductor length & the second cut will remove the
proper length of outer jacket to expose the braid
TXFF Series Ordering Guide
DROP CABLE SHIELD CONNECTOR MANUFACTURER REPLACEMENT BLADES
MODEL PART # COLOR LENGTH WEIGHT
STD. / TRI QUAD CORNING CABELCON AMPHENOL / CORNING GILBERT PPC / PCT 1ST CUT PART # 2ND CUT PART #
TXFF-C 36635 Green ∙ ∙
TXFF-QC 36634 Blue ∙ ∙
TXFF-A/G 36637 Green ∙ ∙ 0.375″ 1 lb 12 oz
TXFF-QA/G 36636 Blue ∙ ∙ CB 26 14403 CB 60 14907 (137 mm) 795 g)
TXFF-P 36639 Green ∙ ∙
TXFF-QP 36638 Blue ∙ ∙

Smart-Strip Series
Data Cable Jacket Stripper

• Versatile & compact tool accurately strips all types of standard insulation on UTP & STP data network
cables, as well as delicate & shielded multi-core cables
• Spring-loaded action & cutting depth adjustment provides precision cutting depths on standard
insulated wire & cables from 0.03″ to 0.039″ (0.75 to 10 mm) in diameter
Smart-Strip Series Ordering Guide
MODEL PART # CABLE COMPATIBILITY STRIPPING DEPTH STRIPPING MATERIAL LENGTH WEIGHT
Smart-Strip 39470 UTP & STP Data Network; Shielded Multi-Core 0.03″ - 0.39″ (0.75 - 10 mm) Standard Insulation 3.8″ (97 mm) 1.4 oz (40 g)

MSES-50 Series
Wireless 50 Ohm Cable Mid-Span & End Stripper

• Self-feeding tool is designed to efficiently strip the jackets on the mid-span & end of wireless 50 ohm
coaxial cable to any length without damaging the conductor
• Spring-loaded locking bolt opens the tool in half for quick & easy cable positioning
• Convenient pull ring serves as a carrying attachment on tool belts and pouches

MSES-50 Series Ordering Guide
REPLACEMENT BLADES
50 OHM CABLE TYPE CABLE SIZE MODEL PART # BODY COLOR LENGTH WEIGHT
MODEL PART #
1/2″ (12.70 mm) MSES-12-50 36812 CB 223 37111 Blue
Andrew / Eupen / NK / RFS 7/8″ (22.23 mm) MSES-78-50 36809 CB 222 37107 Copper
1 1/4″ (31.75 mm) MSES-114-50 36806 CB 217 36795 Gold
1/2″ (12.70 mm) MSES-CR-50-540 37108 CB 235 37138
CommScope® Cell Reach™ Gold
7/8″ (22.23 mm) MSES-CR-50-1070 37104 CB 234 37137
0.4″ (10.16 mm) MSES-GST-400A 42605 4.3″ (109 mm) 12.5 oz (354 g)
0.6″ (15.24 mm) MSES-GST-600 37097 CB 233 37111
Times Microwave LMR® 0.9″ (22.86 mm) MSES-GST-900 37124 Copper
1.2″ (30.48 mm) MSES-GST-1200 37128 CB 222 37107
1.7″ (43.18 mm) MSES-GST-1700 37132 CB 217 36795
