Section 4, Page 3                           EASA AR100-2020 Recommended Practice - Rev. August 2020


            4.2.8  Phase Balance Test                           (3)  Measurement and analysis of the magnetic
              The phase balance test applies balanced reduced       field along the circumference of the rotor with
            voltage 3-phase power to the stator and the current     current applied to the rotor cage via induction
            is measured and checked for balance.                    or direct connection to the end rings.
            4.2.9  Polarity Test                                Caution: The use of shaft clamps can result in stray
 DRAFT
                                                              current paths that reduce the effectiveness of the test
              The polarity test applies direct current, usually to
            a single phase, and the magnetic polarity of the coil   and can affect the physical condition of the rotor or
            groups are checked.                               shaft.
                                                              4.3.3  Armature Windings
            4.2.10 Dummy Rotor Test
              The dummy rotor test uses an artificial rotor such   An insulation resistance test should be performed.
            as a small rotor with a loose fit on a shaft. Reduced   In addition, one or more of the following tests should
            voltage 3-phase power is supplied to the stator and   be performed:
            the rotor is moved circumferentially along the bore   (1)  Growler test.
            to check for continuous rotor rotation.             (2)  Winding surge test.
                                                                (3)  Bar-to-bar test.
            4.2.11  Impedance Test
                                                              4.3.4  Shunt, Series, Interpole,
              The impedance test applies an AC voltage to the
                                                                     Compensating and Synchronous
            two leads of a coil and the voltage and current are
                                                                     Rotor Windings
            measured. Using Ohm’s Law the impedance is calcu-
            lated. The impedance of the individual coils is then   An insulation resistance test should be performed.
            compared for relative equality among coils that are   In addition, one or more of the following tests should
            intended to have equal electromagnetic qualities.  be performed:
                                                                (1) Winding resistance test.
            4.3    RECOMMENDED WINDING TESTS
                                                                (2) Winding surge test.
              Windings should be tested to ensure that there are   (3) AC voltage drop test.
            no grounds (earth faults), short circuits, open circuits,   (4) Impedance test.
            incorrect connections or high resistance connections.
                                                              4.3.5  Interconnection of Windings
            4.3.1  Stator and Wound-Rotor Windings
                                                                Shunt, series, interpole, compensating, and syn-
              The IR, winding surge and winding resistance tests   chronous rotor windings should be tested to ensure
            should be performed. In addition one or more of the   that  the  polarities  and  connections  are  correct.
            following tests may be performed:                 Terminal and lead markings should comply with
              (1)  Phase-balance test.                        Subsection 1.6.
              (2)  Polarity test.
                                                              4.4    HIGH-POTENTIAL TESTS
              (3)  Artificial rotor (dummy rotor) test (low voltage
                  energization).                                High-potential tests should be performed on wind-
              (4)  Polarization index test or dielectric absorption   ings and certain accessories of electrical machines at a
                                                              specified voltage. To avoid excessive stressing of the
                  test.
                                                              insulation, repeated application of the high-potential
              (5)  Insulation dissipation or power factor test.  test voltage is not recommended.
              (6)  Turn-to-turn test.                           Machines to be tested must be clean and dry. Inspec-
              (7)  Partial discharge testing for inception and   tion and insulation resistance tests with acceptable
                  extinction voltage levels.
                  Note: Per CSA C392 the resistance unbalance   results should be performed before the high-potential
                                                              tests. Insulation resistance tests should be repeated
                  limit for random windings should be 2% from
                                                              at the completion of the high-potential tests.
                  the average, and 1% from the average for form
                                                                When a high-potential test is conducted on an as-
                  coil windings.                              sembled brushless exciter and synchronous machine
                  Note: Some concentric windings may exceed   field winding, the brushless circuit components (di-
                  the 2% limit.
                                                              odes, thyristors, etc.) should be short-circuited (not
            4.3.2  Squirrel Cage Windings                     grounded/earthed) during the test.
              One or more of these test methods should be used   High-potential tests should be successively applied
            to produce currents in bars and end rings to detect a   between each winding or electric circuit under test
            defect in the squirrel cage:                      and the grounded (earthed) frame (or core) of the
              (1)  Growler test.                              machine. All other windings or electric circuits not
              (2)  Single-phase test.                         under test should be connected to the grounded
