MEASURING & LEVELING TOOLS

Industrial Safety Welding Oilfield Construction

Protractors Series 187 Universal

Features: Bevel Protractors

• Durable Polycast® construction. •FeaHtiugrheps:recision angle gage for
• Magnetic base and edge.
accurate angle measurement of machines, molds and jigs.
Type: Magnet Protractor
• Can be attached to height gages.
SKU Angle
272‑36 1 ‑ 360 ° Material: Stainless Steel
Type: Mechanical

SKU Blade Length Angle
504‑187‑904 6 in 360 °

Stainless Steel Protractors RADIUS MARKERS

MEASURING & LEVELING TOOLS •FeaAtdujruesst:able protractor arm locks into Radius Markers

desired position with knurled thumb nut. F•eaPtruerceissi:on tools made of rust proof aluminum

• Permanently etched graduations from and anodized for lasting protection.

0 to 180º in opposite directions. • The arms are precisely aligned with spring
Dial Reading: 0‑180‑0
Head Length: 3 3/8 in tension joints to guarantee accuracy and rigidity.
Head Width: 2 in
Type: Universal Protractor • The holder accommodates

SKU Blade Length Angle Head Type flat or round soapstone and pencils.
318‑18 6 in 180 ° Round
318‑17 6 in 180 ° Square • All are a folding type design, the three smaller models

will fit conveniently into a shirt pocket.

• All have sturdy friction joints to maintain rigidity and accuracy.

Material: Aluminum
Includes: Soapstone Crayon

SKU Size Group Radius
430‑14780 Mini 8 in
430‑14781 Small 20 in
430‑14782 24 in
430‑14783 Standard 40 in
Jumbo

C434ME-300 Combination Square/ Radius Markers

Protractor Sets •FeaPtruerceissi:on tools made of rust proof aluminum

•FeaCtoumrebsi:nation set featuring square, center and and anodized for lasting protection.

reversible protractor head and blade. • The arms are precisely aligned with spring tension

• Includes a reversible lock bolt, scriber and spirit level joints to guarantee accuracy and rigidity.

in both the square head and protractor head. • The holder accommodates flat or round soapstone and pencils.
Length: 11 3/4 in • All are a folding type design, the three smaller models
Head Type: Square, Center; Protractor
Material: Steel will fit conveniently into a shirt pocket.
Beam Material: Cast Iron
Blade Finish: Satin Chrome • All have sturdy friction joints to maintain rigidity and accuracy.
Finish: Satin Chrome

SKU Blade Length SKU Size Group
681‑56422 11 3/4 496‑72800 Small
496‑72805 Medium

454 ORSNASCO.COM © 2016
