SAFETY & SECURITY

Industrial Safety Welding Oilfield Construction

Eye Wash & Shower Stations Portable Eye Washes

•FeaEtyuerewsa:sh is activated by flag handle or •FeaSteulrf-ecso:ntained eye wash and drench hose

foot treadle, two GS-Plus™ spray heads units are ideal where a continuous supply
deliver a flood of water for rinsing eyes. of potable water is not available.

• Shower Valve: 1 in IPS chrome plated brass • Tank has built-in carrying handles, air intake

stay-open ball valve, furnished with stainless steel fitting, pressure gauge and pressure relief valve.
actuating arm and 29 in stainless steel pull rod.
• Eye Wash Unit: two GS-Plus spray heads, each
• Spray Head Assembly: Two GS-Plus™ spray
with a “flip top” dust cover, internal flow control
heads each has a “flip top” dust cover, internal and filter, valve is 1/2” IPS chrome plated
flow control and filter to remove impurities from the water flow. brass stay-open ball valve with flag handle.

• Eye Wash Valve: 1/2 in IPS chrome plated brass stay-open ball valve, • Drench Hose: single GS-Plus spray head with

remains in operation until handle is returned to closed position. “flip top” dust cover, internal flow control and
filter, valve is chrome plated brass squeeze
• Pipe and Fittings: Schedule 40 galvanized steel, furnished valve with stainless steel lever handle.

with orange polyethylene covers for vertical piping Test & Approvals: Meets ANSI Standards Z358.1
for high visibility and corrosion resistance. Classified Primary

Test & Approvals: Meets ANSI Standards Z358.1 Classified Primary Bowl Diam: 16 in

Inlet Size: 1 1/4 in Flow: 0.65 gal/min

Outlet Size: 1 1/4 in Capacity Vol.: 15 gal

Hose Length: 6 ft

Hose Material: Reinforced PVC

SKU Bowl Height
333-G1562 39 in

SKU Bowl Height Bowl Diam Bowl Material Eyesaline® Wall Station
333-G1902 36 in 11 1/2 in Stainless Steel Refill Bottles
333-G1902-SSH 36 in 11 1/2 in Stainless Steel
333-G1902P 36 in Safety Orange ABS Features:
12 in
• 16 and 32 oz Eyewash refills contain Eyesaline®
SAFETY & SECURITY
and have extended flow nozzles.

• 32 oz Eyewash and Bodyflush refill bottles feature

integral gripping surface for ease of handling.

• 16 and 32 oz eyewash bottles have bi-lingual,

English/Spanish instructions on label.

EyeSafe™ Faucet- SKU Capacity Vol.
203-32-000454-0000 16 oz
Mounted Eye Washes 203-32-000455-0000 32 oz

•FeaCtounrveesr:ts any faucet into Eyesaline® Wall Stations

an emergency eye wash F•eaMtuoruenst:s to wall with provided screws.
station without interfering • Overhang protects bottles from dust and debris.
with normal faucet operation. • Twist off, tamper resistant tabs prefent leaking

• Float off dust covers to protect outlet heads. and are easily removed in an emergency.
• Forged brass diverter valve.
• Body has 55/64”-27 female thread. • Holds factory-sealed, sterile, preserved, buffered
• Pull knob to activate eye wash.
• water pressure holds eye wash in operation, leaving user’s hands free. saline solution bottles firmly in place for easy access in an emergency.

Test & Approvals: Meets ANSI Standards Z358.1 Classified Personal or • Simple, highly visible, operating insutructions are provided on each unit.
Secondary • Durable, easy to clean plastic.
Inlet Size: 55/64 in-27 (female)
Outlet Size: Aerator SKU Capacity Vol.
203-32-000460-0000 16 oz
SKU Type 203-32-000461-0000 32 oz
333-G1100 Faucet Mounted 203-32-000462-0000 32 oz
