108 CEILING LIGHTS INDOOR · BIG LIGHT 2017

TUBE
LED TRILEDO ROUND CL TRILEDO SQUARE CL
• Glass and steel construction • 625 lumens • 625 lumens
• Pure geometric shape • Modern aesthetic design • Modern aesthetic design
• Agreeable diffused light • Pivotal LED source • Pivotal LED source
Lamp details Lamp details Lamp details
LED 1x 20W 3000K CRI>90 LED 1x 6.7W 3000K CRI>90 LED 1x 6.7W 3000K CRI>90

Product details Product details Product details
120V 120-277V 120-277V
Total consumption: 20W Total consumption: 9W Total consumption: 9W
Material: Glass/Steel Material: Aluminum Material: Aluminum
Ø: 9.84 in. H: 5.5 in. Ø: 3.35 in. H: 4.25 in. L: 3.35 in. W: 3.35 in. H: 4.25 in.
dimmable: L, C dimmable: C dimmable: C
Canopy Ø: 4.25 in. Canopy H: 0.5 in. Canopy L: 4.33 in. Canopy W: 4.33 in.
Canopy H: 0.5 in.

120° 7.17 50000 38° 1.8 40000 38° 2.8 40000

100° 30° 100° 30°

9.84” 4.25” 4.33” 4.33”
.5” .5”
5.5” 4.25”
4.25”

3.35”
3.35”

Variant Item No. Variant Item No. Variant Item No.
1800lm 625lm 625lm
White 711253A Black 113930U Black 113940U
White 113931U White 113941U
Silver/Gray 113934U Silver/Gray 113944U
Coming soon: 2nd Qtr. 2017 Coming soon: 2nd Qtr. 2017
