CUSTOM COMPRESSION CONNECTOR SELECTION FORM Information Required at Factory

CONDUCTOR TYPE:                                                                               AWG, KCMIL, MCM, MM2 (circle one)
Material (copper, aluminum, ACSR, weld, DLO, etc.)
Conductor Size
Stranding (solid, stranded, compact, etc.)
Conductor class (B, C, I, K (weld), DLO, H, G, M, Metric, Navy, Aircraft, etc.)
Bare, Plated, Insulated

PRODUCT PROFILE:

Connector Material (Copper, Aluminum, etc.)				Connector Type (Lug, Splice)

Barrel Length (Standard, Long)					                                      Barrel Style (Standard, Flared)

Lug Transition Area (Closed Barrel, Inspection Window)

Pad mounting configuration (number of holes, blank, slotted, etc.)

Pad mounting hole diameters and location				                             Pad mounting hole center to center dimensions

Plating (bare, tin, silver, nickel, etc., and thickness)

Agency Standards or listings required (UL, CSA, ANSI, NEMA, etc.)

Special temperature requirements

Mounting hardware required: size & material (bronze, aluminum, steel, stainless steel, etc.)

ADDITIONAL PRODUCT CHARACTERISTICS:

Mounting Pad: Standard Width, Narrow tongue				                          Straight, 45° or 90° configuration

Product Application

Environmental Conditions						Installation tooling considerations

Other

Attach sketch, photo, sample, drawing                                    Estimated annual quantity
Quantity required initial order
Delivery date required

COMPANY PROFILE

Company Name

SIC Code

Address

City			           State	          Country			                        Zip
                                       Fax
Phone				                                                                                     Copy & Fax or Email to:
                                                                                                  Fax: 814.734.4946
Contact Name
                                                                                                info@penn-union.com
Title

Email
