1 C ONT
PHASE 8ENTS PAGE
PAGE DRAWING
2 ASSET PLAN
3 INTERNAL FINISHES - BAKERY
4 INTERNAL FINISHES – CANTEEN/OFFICE
5 DOOR SCHEDULE AND FINISHES
6 WELFARE & SITE SET UP
7 FIRE STRATEGY
8 CONTAINMENT
9 POWER
10 LIGHTING
11 LIGHTING SCHEMATIC
12 DATA
13 FIRE ALARM
14 HOT WATER
15 COLD WATER
16 VENTILATION
17 CEILING CLASH
18 REFRIGERATION – GENERAL LAYOUT
19 REFRIGERATION – SERVICE ROUTES
20 REFRIGERATION – PLANT LAYOUT
21 DRAINAGE LAYOUT – BELOW GROUND
22 DRAINAGE LAYOUT – ABOVE GROUND
23 COLDROOM LAYOUT
24 EXTERNAL YARD
25 EXTERNAL SIGNAGE
