Page 100 - 2025 MORRIS Diversitech HVAC Catalog

THERMOSTATS & CONTROLS
THERMOSTATS & CONTROLS
Wifi Thermostats
Wifi Thermostats

• Exclusively for HVAC professionals
• T855iSH is Compatible with every PRO1 subbase
• T721i is Compatible with any 2H/1C Heat Pump or 1H/1C
Conventional PRO1 subbase
• T701i is Compatible with any 1H/1C Conventional PRO1
subbase

T855iSH T751i, T721i, T701i

CAT. Heat and Power Programming Case
NO. Cool Stages Source Qty
7 Day or
T855iSH Up to 2 Heat, 2 Cool Conventional Hardwire Only Non-Programmable 10
Up to 5 Heat, 3 Cool Heat Pump
2 Heat, 2 Cool Heat Pump Programmable
T751i 4 Heat, 2 Cool Conventional Hardwire Only Through App 10
2 Heat, 1 Cool Heat Pump Programmable
T721i 1 Heat, 1 Cool Conventional Hardwire Only Through App 10
WIFI Thermostats / Accessories
T701i 1 Heat, 1 Cool Only Hardwire Only Programmable 10
Through App
PRO1 Thermostat Guard
PRO1 Thermostat Guard

• Fits on every PRO1 thermostat
• Fits over an installed thermostat
• Includes 2 keys

CAT. Works Dimensions Case
NO. With Height Width Depth Qty
T150 All Pro1 Thermostats 6.25" 3.25 8.25" 5
Plastic Thermostat Guards
Plastic Thermostat Guards

• Used to prevent tampering with thermostats
• Covers are clear, allowing complete view of the thermostat and
585-TG1 current settings
• Includes vent holes for easy airflow across the thermostat
• Lockable with universal key
• Includes mounting screws and key

CAT. DESCRIPTION T-STAT Case
NO. CLEARANCe Qty
585-TG Clear Plastic w/Two Bases 8-1/4” x 4-1/2” x 3-1/4” 18
585-TG1 Clear Plastic w/Two Bases 5-3/4” x 3-1/2” x 2-3/4” 18

585-TG6 Clear Plastic w/Two Bases 6-1/4” x 3-3/4” x 1-3/4” 18
585-F336 Key for Thermostat Guard - 1
97 FOR THE FULL RANGE OF DIVERSITECH PRODUCTS PLEASE VISIT www.DIVERSITECH.COM
Images and Specifications may not be representative of all products listed.
www.morrisproducts.com 1-888-777-6678
