Page 113 - 2016-2017 Racecar Engineering Late Model Muscle Car Parts and Accessories Catalog

Corvette (C6) Trans Mounts
AFE450-401008-N
Improve vehicle launch and traction while still of-
fering a comfortable ride. These upgraded transmission mounts feature
Corvette (C5/C6) Control Arm Bushings polyurethane bushings, CNC machined 6061 anodized T6 aluminum
mated to nickel plated chassis mounts and grade 10.9 hardware. Fits
Specialty grooved, graphite 2005-13 Corvette (C6) applications. Sold as pair.
impregnated polyurethane bush-
ings combined with 6061 hard an-
odized T6 aluminum sleeves and Corvette (C5/C6) Engine Mounts
shafts offer improved handling AFE450-401007-N
and a comfortable ride suitable for
both track and street use. The upgraded engine mounts reduce drivetrain deflec-
Part No. Description tion and improve traction while still offering a comfortable ride for
AFE470-401001-B ......1997-03 C5/C6, Steel Frame the street. The pair of mounts feature harder durometer polyurethane
AFE470-401002-B ......2006-13 C6 Z06/ZR1, Aluminum Frame bushings, CNC machined 6061 anodized T6 aluminum mated to nickel
plated chassis mounts and grade 10.9 hardware. Fits 1997-13 Corvette
(C5/C6) applications.
Corvette (C5/C6)
Control Arm Solid Spherical Bearings Corvette Street Tri-Y Headers & X-Pipes
Eliminate OE factory con- The Tri-Y design maximized torque
trol arm bushing deflection throughout the powerband
with solid spherical control while the 200CPSI stainless
arm bushings. The American steel converters maximize
made low friction teflon flow and performance without
lined mono-ball spherical creating check engine light issues.
joints combined with The X-Pipe balance tube equalizes
lightweight 6061 aluminum pressure to minimize engine drone and increase flow and performance.
housings offer improved cornering for the serious racer. Part No. Description
Part No. Description AFE48-34103-YC ........1997-04 C5 V8-5.7L
AFE460-401001-A ......1997-13 C5/C6, Steel Frame, Track Tuning AFE48-34105-YC ........2005-08 C6 V8-6.0L
AFE460-401003-A ......2006-13 C6 Z06/ZR1, Aluminum Frame, Track Tuning AFE48-34107-YC ........2005-13 Z06/ZR1, C6 V8-7.0L
AFE48-34109-YC ........2009-13 C6 V.8-6.2L
Corvette (C5) Trans Mount AFE48-34112-YC ........2014-15 C7 V8-6.2L
AFE450-401011-N 1997-2004 C5 Tow Hooks
Reduce drivetrain deflec- The Pfadt Series tow hooks are manufactured from 3/16” thick A36
tion and improve traction steel and are laser cut and MIG welded for precision and strength.
while still offering a comfort- Includes mounting hardware.
able street ride. The mount features harder durometer polyurethane Part No. Description
bushings, a CNC machine 6061-T6 anodized aluminum brace that’s AFE450-401002-L ......Front Blue
mated to nickel plated mounts, and grade 10.9 hardware. Fits 1997-04 AFE450-401002-R ......Front Red
Corvette (C5) applications. AFE450-401003-L ......Rear Blue
AFE450-401003-R ......Rear Red AFE450-401002-L

Corvette Air Intake Systems
High flow, cold air intake systems have one-piece cold air boxes and
blade style weatherstrips to isolate engine heat from the filter.
Part No. Application
ARA250-216 ...2006-13 Corvette Z06, 7.0L
ARA250-218 ...2005-07 Corvette V8, 6.0L
ARA250-292 ...2001-04 Corvette V8, 5.7L
ARA251-292 ...2001-04 Corvette Dry Filte,r V8 5.7L

Chevy corvette
™
Auto Meter Gauge Works now offers a variety of mounting options for 1997 to 2009 Chevy
f the
Corvette. Custom designed for each model, the mounting accessories provide easy viewing of the
gauges, and have a factory-installed appearance.
Corvette Gauge Pods And Pillar Pods
Single Pod Dual Pillar Pods Triple Pillar Pods
Car Model 2-1/16" 2-1/16" 2-1/16"
Corvette 1997-02 ATM10193 ATM12192 —
Corvette 2003-04 — ATM12193 —
Corvette 2005-09 — ATM12194 ATM12195
TM
Note: Gauges not included with Gaugeworks products
