Page 40 - 2016-2017 Racecar Engineering Late Model Muscle Car Parts and Accessories Catalog
P. 40
8.8" Ford 31 Spline MEIA883105
Forged steel axles fit your 2005 & newer Mustang 5 lug w/ABS adapter. Axles are non-tapered, with hardened &
ground bearing seats and machined c-clip grooves. If you choose to narrow your rear end at a later time, these axles
can also be shortened and resplined.
DIS-4 Harnesses
Specialized wiring harnesses offer a
splice-free installation of DIS ignition
systems.
Pro-Billet Drop-In Distributor Part No. Description
Machined aluminum housing has an upper sealed MSD88812 .....DIS-4 To Dual Ford Coil Packs
ball bearing that eliminates shaft wobble. Features MSD88813 .....Dual DIS-4 Installation
include Rynite distributor cap, adjustable mechani- Note: A complete installation on a late model Ford requires two DIS-4
cal advance, hardened 10,000 RPM plus shaft, Plus Ignition Controls and four MSD89121 Ignition Adapters.
extra advance springs, advance bushings and high
output magnetic pickup for years of reliable service. Ford 4-Tower Coil Pack MSD8241
Part No. Application Advance Ignition System High performance ignition coil is designed for
MSD8455 Ford 1994-95 5.0L Electronic OEM/MSD
1995-98 Ford 4.6L DOHC/SOHC.
Two-Step
For Ford Mod Motors
Two-step delivers improved 60’
Blaster Ignition Coils times and consistent launches by al-
lowing set RPM limits. Once activated,
All coils include coil boot, terminal and ballast the RPM will hold steady RPM until
resistor (when required).
the clutch is released, which removes
Part No. Description Ignition Applications the limit. Two built-in rotary dials al-
MSD8202 Blaster 2 Red Coil Late Model Electronic low adjusting RPM from 1,800-9,900
MSD8222 Blaster High Vibration Coil MSD 6 or 7 RPM in 100 RPM increments, while
MSD8227 ‡ Blaster TFI Coil Late Model Ford Electronic an LED indicator displays when the launch limit is activated. Unit plugs
‡ Use MSD8874 for a direct plug-in installation. directly to the factory coils for easy installation.
Part No. Description
MSD8734 ......Two-Step For Ford 4.6L Mod Motors
Ford Modular Engine Ignition Components MSD8731 ......Two-Step For Ford 5.0L Mod Motors, 2011-Up
6-Mod Ford Modular Ignition Controller MSD6011
Retrofit a Ford 4.6L or 5.4L (SOHC/DOHC) TECH TIP
with a carbureted intake manifold and use Recommended Mustang Ignition Components
this new controller to handle the ignition
chores. Unit plugs into the coil packs and Year Model Part No. Description
sensors of the engine for a direct installation. &..*"'%%) ;dgY BjhiVc\
With a PC using Pro-Data+ software, the 1995-98 Mustang 4.6L SOHC/DOHC MSD8241 4 Tower Coil Pack
unit can be programmed for a custom timing 1996-04 Mustang 4.6L 2V/4V MSD62152 DIS-4 Ignition Box
curve, a step retard, two-step rev limiter and 1996-98 Mustang 4.6L 2V/4V MSD88812* DIS-4 Wire Harness
even adjust vacuum advance.
1999-04 Mustang 4.6/5.4L 2V/4V MSD88813** DIS-4 Wire Harness
DIS-4 Plus Ignition Controller MSD62152 1999-04 Mustang 4.6/5.4L 2V/4V MSD8734‡ Two-Step
MSD82428
1999-04 Mustang 4.6L SOHC
Blaster Coil-On Plugs (8-Pack)
Designed for 6- or 8-cylinder engines 1999-04 Mustang 4.6L DOHC MSD82448 Blaster Coil-On Plugs (8-Pack)
with two, three or four coil packs, or waste '%%*"'%1% ;dgY BjhiVc\
spark ignition systems. Ignition delivers full 2005-10 Mustang 4.6/5.4L SOHC MSD62152† DIS-4 Ignition Box
power Capacitive Discharge sparks from 2005-10 Mustang 4.6/5.4L SOHC MSD88813† DIS-4 Wire Harness
idle through racing RPM, while below 3,000 2005-10 Mustang 4.6/5.4L SOHC MSD8734‡ Two-Step
RPM there is a series of multiple sparks to
improve idle, starting and throttle response. 2005-10 Mustang 4.6/5.4L SOHC MSD82438 Blaster Coil-On Plugs (8-Pack)
The adjustable features of the DIS ignition are '%11"'%1) ;dgY BjhiVc\
upgraded with easy-to-use rotary dials. A step retard is 2011-14 Mustang 5.0L MSD8731‡ Two-Step
also incorporated, which may be wired directly to a nitrous system or 2011-14 Mustang 5.0L MSD82488 Blaster Coil-On Plugs (8-Pack)
switch for activation. Notes: * Requires (2) MSD88812, (2) MSD62152 and (4) MSD89121
for complete installation. ** Requires (1) MSD88813 (2) MSD62152,
† Requires(2) MSD62152, (4) MSD89121 Tach Adapters For Complete
Install.
‡ Connects directly to the factory coils.
