SUSPENSION

COIL-OVER LOAD BOLT ASSEMBLY EXTENDED LENGTH
ALL56074 UPPER SPRING CUP ALL56125
Threaded aluminum bolt is 6" long with 1-1/8"-12 fine threads Commonly used in rear suspensions, cup connects to jack
and is commonly used on big bar soft spring cars. Load bolt offers bolt with a bolt and O-ring to help maintain spring location.
the ability to easily change corner weights, change the center to Extension sits 5" into the spring.
center distance of the shock, adjust bump stop distances without
adding shims and adjust ride height without running out of shock
travel. Commonly used with ALL56098 threaded sleeve.
Part No. Description EXTENDED LENGTH
ALL56075 Replacement Shock End “SWIVELER” SPRING CUP
ALL56079
UPPER SPRING CUPS Extended length cup helps keep spring centered. Also
Steel cups work with most 5" and 5-1/2" O.D. springs keeps spring from falling out on some modern day long drop
and either 1" or 1-1/8" jack bolts. suspension packages.
Part No. Description
ALL56114 Standard Cup For 5" Spring
ALL56115 Oversized Cup For 5-1/2" Spring ALL56114
COIL SPRING SPACER
ALL56116
LIGHTWEIGHT UPPER Spacer for 5" racing spring welds into spring pocket
SPRING CUP ALL56113 enabling chassis adjustments to street stock and other
Lightweight steel cup works with most 5" and 5-1/2" O.D. race cars that are not allowed to use weight jack bolts
springs and either 1" or 1-1/8" jack bolts. or threaded adjusters. 3" tall spacer may be cut to desired
height before installation. Use coil shim spacers ALL56120
and ALL56121 to make chassis adjustments.
BOLT-ON UPPER SPRING CUP
ALL56097 COIL SPRING SHIMS
Steel upper spring cup bolts to internal thread jack Used with ALL56116, or whenever weight jack bolts are not allowed, to raise
bolts, keeping spring centered. car height for set-up purposes. 5" diameter, 3-5/8" I.D.
Part No. Description
ALL56120 3/16" Shim
“SWIVELER” SPRING CUPS ALL56121 1/8" Shim
Swiveler cup is used in place of a standard upper spring plate and weight ADJUSTABLE COIL SPRING SPACERS
jack bolt on vehicles using conventional style coil springs. Mono-ball stud
mount allows cup to pivot as needed to prevent binding during suspension Spacer adapts racing front springs for use on street stock cars where weight
travel and requires a weight jack bolt with a 7/16"-20 internal threaded end for jack bolts are not allowed.
proper installation.

WELDED STYLE ALL56080
The sleeve and top are welded together on this unit to fit
most applications using a 5" conventional spring.
ALL56118 ALL56119
Part No. Description
PRO-SERIES ALL56118 All Steel Assembly
Components bolt together to select the desired spring top plate and sleeve ALL56119 Steel Sleeve With
separately to build custom size cups. Aluminum Adjustment Nut
SHOCK TRAVEL
INDICATOR KITS
Check compression and rebound travel of coil-over
shocks at a glance. Clamp aluminum bracket portion
of the kit directly to the coil-over sleeve or shock
ALL56077 ALL56086 body and attach the other end to the existing shock
Part No. Description eye bolt or under spring cup. May be used with
ALL56077 Spring Top Plate For 5" Spring most coil-over and non-coil-over shocks. Clamp is
ALL56078 Spring Top Plate For 5-1/2" Spring included.
ALL56086 3.25" Spring Sleeve Part No. Description
ALL56087 3.50" Spring Sleeve ALL60094 Kit For Use With
2-1/2" Spring
ALL56088 3.75" Spring Sleeve Kit For Use With
ALL56089 4.00" Spring Sleeve ALL60095 3" Barrel or 5" Springs
ALL56085 4.25" Spring Sleeve
ALL60094 ALL60095
