P. 195
BEARING GAS PEDAL BSB3015 ADJUSTABLE J-BAR
Gas pedal assembly includes a sealed bearing for Adjustable J-bar, which includes
smooth, consistent travel. Ideal for dirt or asphalt a 6" drop, may be adjusted on
applications, assembly is adjustable at both ends for the car. Two lengths available.
increased driver comfort. May be mounted straight, Part No. Description
or up to 8°. BSB7039-19 18-3/4" To 21-1/2"
BSB7039-20 20" To 22-3/4"
XD SERIES ADJUSTABLE J-BARS
DOUBLE SIDED ADJUSTABLE The strongest steel J-bar currently
PINION BRACKET available. XD Series J-Bar features a
BSB4039S 6" drop and may be adjusted without
Designed for use with Quick Change rears, removal from the car. Offered in two
rigid, 1" thick pinion bracket allows performing different lengths.
Panhard bar adjustments without removal. Part No. Description
Constructed from billet aluminum and BSB7045-19 Adjustable J-Bar, 18-3/4"-21-1/2"
engraved for easy adjustments, bracket BSB7045-20 Adjustable J-Bar, 20"-22-3/4"
is fitted with oil seal and is sold complete with
spacer bushing and lock nut.
FRAME SLIDER BSB3056
DOUBLE SIDED Frame mount slider, which features multiple
ADJUSTABLE/ANGLED PINION BRACKET overlapping holes in an arc pattern, elimi-
BSB4036 nates the need to adjust Panhard bar
Rigid billet aluminum pinion bracket is length. Billet aluminum construction
not only double sided and adjustable, slider fits 2" square tube frame rails.
but angled to allow movement of
the J-bar without changing length.
Bracket includes built-in seal and
adjustment lines on both sides.
Sold complete with one adjuster, CLIMBING FRAME SLIDER
bushing and bolts. BSB3048-20
Engineered specifically for Rocket chassis and con-
CLIMBING PINION PLATE structed from rigid billet aluminum, innovative slider
BSB7027 allows adjusting J-bar without bolt removal. Designed
for use with 2" x 2" tubing, adjustments may be
Heavy duty steel, Climbing Pinion Plate performed using a single wrench.
allows adjusting the J-bar up and down
without having to remove it, while using
just a single wrench. Plate is 1/2" thick
and 3/4" thick at gear adjuster
BSB7055-15
ADJUSTABLE PINION PLATE
Steel Pinion Plate includes increased area FRAME SLIDERS
of adjustment. Adjustments can be per- Steel construction Frame Sliders
formed using a single wrench. Sold complete allow moving the Panhard bar up or
with mounting hardware. Offered for Ford 9" down without affecting the length.
or Quick Change.
Offered in standard or double sided versions.
Part No. Description
BSB7036 Ford 9" Part No. Description
BSB7038 Quick Change BSB7054-15 Steel Frame Slider, 1.5" x 1.5" Tubing
BSB7054-20 Steel Frame Slider, 2" x 2" Tubing
BSB7055-15 Steel Double Sided Frame Slider, 1.5" x 1.5" Tubing
BSB7055-20 Steel Double Sided Frame Slider, 2" x 2" Tubing
BSB7576 Steel GRT Frame Slider, 2" x 2" Tubing
PINION PLATE STUD KITS XD SERIES
Each kit is sold complete with stud, bushing, nut, CLIMBING FRAME SLIDER
long bolt and nut. Kits are available for use with
aluminum or steel pinion plates. BSB4047S BSB7057-20
Part No. Description Heavy duty, 3/4" thick climbing design steel slider
BSB4047A Aluminum Pinion Plate Stud Kit allows adjusting the bar up or down without having to
BSB4047S Steel Pinion Plate Stud Kit remove it from the car. May be adjusted up or down
using a single wrench.
