Page 403 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

10" WHEEL STANDS DRYAIR JOE32120
JOE29600 The most effective control for humidity
Aluminum, 10" wheel stands allow suspension at the shop or at the track. DryAir may be used
adjustments while the car rests on the wheels. Sold with compressed air or compressed nitrogen and
in sets of four. includes a special desiccant formula that has the drying
capacity of 2-1/2 times its weight. Very effective in high
COIL-OVER SPANNER WRENCHES humidity or low temperature conditions.
Billet aluminum wrenches prevent BALL JOINT SOCKETS
knuckle injuries when adjusting
coil-overs. Eases ball joint installation. Machined steel, zinc plated
sockets accept a 1/2" drive ratchet or breaker bar.
Part No. Description
Description
Part No.
JOE33000 Long JOE40050 Upper Ball Joint Socket
JOE33500 Short JOE40075 Lower Ball Joint Socket JOE40050
BUMP STOP SHIM KIT SPINDLE NUT SOCKET
Designed for shocks with 1/2", 14mm JOE40000
or 5/8" shafts, kit uses a special tool Billet aluminum socket is gray anodized and fits 5x5 or
and shims for quick installation of bump
stop shims. A quick push and the shim wide 5 nuts. Fits a 1/2" drive ratchet.
snaps into place. Each kit includes case,
bump stop wrench and (4) each: 1/16", 1/8", DOUBLE END AN WRENCH SET
1/4" and 3/8" shims. JOE18000
Part No. Description AN wrenches are precision machined
9485 Bump Stop Shim Kit, 5/8" Shaft from billet, 6061-T6 aluminum and are
JOE19490 Bump Stop Shim Kit, 1/2" & 14mm Shaft designed to allow tightening or loos-
ening a fitting in as little as 15°
UPPER SHOCK MOUNT BUMP increments. Bright anodized,
STOP JOE19475 five-piece set includes
-6, -8, -10, -12 and -16
Upper front shock mount welds to the top bar, while the wrenches.
slider action design allows setting the shock body in the desired
position.

SHOCK WORKSTATION
Fixture secures body and shaft of
a shock absorber to allow easier
servicing. May be used in a vise or TOOL BOX LABELS
mounted permanently to a work JOE17500
bench or pit cart with the optional Stick-on labels help organize tool box,
base. saving time when locating tools.
Part No. Description
JOE19200 Shock Workstation
JOE19250 Shock Workstation Base Only
JOE19075 ShockWrench, Allows Penske Shock Disassembly/Assembly
JOE19300 Drip Cup, Catches Shock Oil When Rebuilding
JOE19079 Shockwrench, Allows AFCO Shock Disassembly/Assembly
QUICK RELEASE CANISTER MOUNT
Canister mount has a quick release nylon strap to secure any remote canister
from 1-1/2" to 3" dia.
Part No. Description
JOE19410 Clamps To 1-1/4" Tubing
JOE19412 Clamps To 1-1/2" Tubing
JOE19414 Clamps To 1-3/4" Tubing
JOE19430 Canister Panel Mount
JOE19445 Replacement Strap
JOE19450 Replacement Pin

PHIL BOZELL
