Page 410 - 2017 Racecar Engineering Circle Track Parts and Accessories Catalog

ALUMINUM DUAL DOWEL PIN CRANKSHAFT PULLEY
POWER STEERING PUMPS JRPCS-5102-WC-H
Jones' offers two power steering pump/reservoir Durable, billet aluminum serpentine crankshaft pulley
combos with choice of integral 16 oz. plastic or 18 oz. features an extra groove to ease belt alignment or when
fabricated aluminum reservoir with heavy duty billet used with a 6PK belt for extreme applications. Six-groove,
mounting brackets. Pump may also be purchased separately. 1" wide pulley includes a 1" I.D. and a 4.25" O.D. Should be
Part No. Description used in conjunction with dual dowel pin belt guide.
JRPPS-9008-AL Power Steering Pump Only Part No. Description
Power Steering Pump JRPBG-6108-WC Dual Dowel Pin Crankshaft Pulley Belt Guide
JRPPS-9008-AL-AR
With Fabricated Aluminum Tank
JRPPS-9008-AL-R Power Steering Pump With Plastic Tank
Power Steering Pump Accessories HTD BELTS
JRPPS-3106-B-6.000 V-Belt P/S Pulley, 6.0” Dia., Press-Fit Heavy duty, radius tooth HTD belts feature
JRPPS-5106-B-5.000 Serpentine P/S Pulley, 6-Groove, 5.0" Dia., Press Fit popular, 8mm pitch and are offered in 10mm,
JRPPS-5106-B-6.000 Serpentine P/S Pulley, 6-Groove, 6.0” Dia., Press Fit 20mm and 30mm widths.
JRPPS-6106-B-33 HTD P/S Pulley, 33-Tooth, 1” Wide, Press Fit 10mm 20mm 30mm
JRPPS-6106-B-40 HTD P/S Pulley, 40-Tooth, 1” Wide, Press Fit Length Part No. Part No. Part No.
SB Chevy P/S Mounting Kit, LH, 18.898" JRP480-10HD JRP480-20HD –
JRPPS-8001-SB-R Accepts JRPPS-9008-AL-AR Pump
Lightweight Aluminum P/S Reservoir, 22.047" JRP560-10HD JRP560-20HD –
JRPPS-9008-AR3 22.677" – JRP576-20HD –
Includes Aux. Bung And Billet Cap
23.622" JRP600-10HD JRP600-20HD JRP600-30HD
23.937" JRP608-10HD – –
SYNTHETIC 24.567" JRP624-10HD JRP624-20HD JRP624-30HD
POWER STEERING FLUID 24.882" JRP632-10HD JRP632-20HD JRP632-30HD
JRPPS-8009-32S 25.197" JRP640-10HD JRP640-20HD JRP640-30HD
JRP656-10HD
25.827"
JRP656-20HD
–
Fully synthetic power steering fluid features a clear formula to 26.457" JRP672-10HD JRP672-20HD –
ease viewing of impurities throughout the life of the fluid. Offered 26.772" JRP680-10HD JRP680-20HD JRP680-30HD
in 32 oz. bottle.
27.402" – JRP696-20HD –
28.346" JRP720-10HD JRP720-20HD –
RADIUS TOOTH HTD PULLEYS 28.976" – JRP736-20HD –
HTD pulleys are manufactured from aircraft quality billet aluminum. 30.551" – JRP776-20HD –
Part No. Description 30.866" – JRP784-20 –
Alternator Pulley, 18-Tooth HTD, 31.496" – JRP800-20HD –
JRPAL-6105-18-B
.669" (17mm) I.D., 1" Wide 33.071" – JRP840-20HD –
Oil Pump Pulley, 36-Tooth HTD, 33.701" JRP856-10HD – –
JRPOP-6103-36-11/4 5/8" I.D., 1-1/4" Wide,
3/16" Keyway, 5 Set Screws 34.646" – JRP880-20HD –
Oil Pump Pulley, 38-Tooth HTD, 35.906" – JRP912-20HD –
JRPOP-6103-38-1-1/4 5/8" I.D., 1-1/4" Wide, 3/16" JRPAL-6105-18-B
Keyway, 5 Set Screws
Oil Pump Pulley, 40-Tooth HTD, GILMER BELTS
JRPOP-6103-40-1-1/4 5/8" I.D., 1-1/4" Wide, 3/16" Gilmer style (cog) belts are used to drive dry
Keyway, 5 Set Screws sump oil pumps and other engine accessories.
Water Pump Pulley, Part No. Description
JRPWP-6104-37A
37-Tooth HTD, 0-1.9" Deep JRP233-L-100 1" Wide, 23.25" Long
JRP236-L-100 1" Wide, 23.625" Long
BELT GUIDES JRP248-L-100 1" Wide, 24.75" Long

SERPENTINE BELTS
Choose from 5- or 6-groove serpentine belts.
JRPBG-6108-36C 5-Groove 6-Groove
JRPBG-6108-C
Part No. Description Length Part No. Part No.
Crankshaft Pulley 27.165" JRP5PK-690HD –
JRPBG-6108-C 1-1/16" Wide, 3.500" O.D. x 1.125" I.D., Fits 26-35 27.362" JRP5PK-695HD JRP6PK-695HD
Radius Tooth Or 23-28 Square Tooth 33.465" JRP5PK-850HD –
1-1/16" Wide, 2.500" O.D. x 1.125" I.D., Fits 17-22 35.039" JRP5PK-890 –
JRPBG-6108-F
Radius Tooth Or 12-20 Square Tooth 36.024" JRP5PK-915 –
Oil Pump, Fuel Pump & Vacuum Pump, Bolt-On 37.008" JRP5PK-940 –
JRPBG-6108-36S Fits 36-Tooth, Radius Tooth Pulleys
JRPBG-6108-38S Fits 38-Tooth, Radius Tooth Pulleys
JRPBG-6108-40S Fits 40-Tooth, Radius Tooth Pulleys
